Three-phase electric power is a type of polyphase system that employs three wires (or four, including an optional neutral return wire) to transmit power. It is the most common method used by electrical grids worldwide to transfer power. In a three-phase power system, the voltage on each wire is 120 degrees phase-shifted relative to each of the other wires. This allows for the voltages to be easily stepped up or down using transformers, making it a highly efficient system. Three-phase power is commonly used in commercial and industrial applications that require large motors and heavy machinery.
| Characteristics | Values |
|---|---|
| Type | Alternating current (AC) |
| Phases | Three |
| Wires | Three or four (including an optional neutral wire) |
| Voltage | 120/208 V or 277/480 V |
| Phase Shift | 120 degrees |
| Applications | Commercial, industrial, data centres |
| Efficiency | Higher than single-phase |
| Load | Better suited for higher loads |
| Cost | More cost-effective |
| Breakers | Large enough to span three poles |
| Bus Bars | Three positive/line bus bars |
Explore related products
What You'll Learn
- Three-phase electric power is a common type of alternating current (AC)
- It is used in electricity generation, transmission, and distribution
- Three-phase power systems provide three separate currents
- Each of the three power wires is 120° out of phase with each other
- Three-phase power is used in industrial and commercial applications
Three-phase electric power is a common type of alternating current (AC)
In a three-phase power system, the voltage on each wire is 120 degrees phase-shifted relative to each of the other wires. This means that the power never drops to zero since three simultaneous cycles are occurring. This steady stream of power allows three-phase power to handle higher loads, making it suitable for industrial and commercial applications. For example, three-phase power is commonly used to deliver electricity to data centres and commercial and industrial buildings housing power-hungry machinery.
The ability to deliver large amounts of power efficiently is especially important as data centres and server rooms continue to see higher densities. More powerful computing systems are being packed into the same spaces that once housed servers that drew only a fraction of the electrical power that today's computers and networks demand. Three-phase power is more efficient than single-phase power, as it can deliver the same power (and more) using smaller wiring.
Three-phase power is also more cost-effective than single-phase power. A three-wire three-phase circuit is usually more economical than an equivalent two-wire single-phase circuit at the same line-to-ground voltage because it uses less conductor material to transmit a given amount of electrical power. However, one disadvantage of three-phase power is that it cannot handle overload, which may damage equipment and lead to costly repairs.
