Daisy chaining is a common wiring scheme in electrical engineering, where multiple devices are connected in sequence or in a ring, resembling a garland of daisies. This configuration is used to increase the total current, transmit analog signals, or share digital data. Daisy chaining is often used for power supplies, especially in industrial applications, where the outputs of several power supplies are directly connected to increase the overall current. However, it is important to exercise caution as overloading circuits can lead to safety hazards such as fire risks.
Explore related products
What You'll Learn
- Daisy chaining is a wiring scheme in which multiple devices are connected in sequence
- It can be used to achieve a higher total current and to transmit data
- Daisy chaining can be used for power supplies, but not all are suitable or approved for it
- It is important to check the data sheet for the power supply before setting up a daisy chain
- Daisy chaining can be used to save time and money by using only one power supply for multiple products
Daisy chaining is a wiring scheme in which multiple devices are connected in sequence
In a daisy chain, the wiring for each device is connected to the previous device's electrical terminals, creating a chain-like arrangement. This can be done with devices wired together in a linear or ring-shaped fashion, similar to a garland of daisies. The principle can be used to achieve a higher total current, or to transmit analog signals or digital data.
Daisy chaining is a common practice in industrial applications, but it should be approached with caution. It is important to check the data sheet for the relevant type of power supply before setting up a daisy chain, as some power supplies do not allow for the direct connection of outputs. If this warning is ignored, it can lead to overloaded circuits and even fire hazards.
Additionally, as devices are interconnected in a daisy chain, the electrical current encounters resistance in the wires, which can lead to a voltage drop. This means that devices furthest from the power source may experience a lower voltage supply compared to devices closer to the source, potentially impacting performance and efficiency.
