In electronics, floating refers to a circuit configuration in which neither wire carrying the signal is connected to the system ground. This is also known as a floating ground. A floating ground is a reference point for electrical potential in a circuit that is galvanically isolated from the actual earth ground. In other words, a floating power supply can be used with the output floating off the ground. This is usually done for safety reasons, as it makes it much easier to guarantee the safety of the supply.
Explore related products
Floating ground
A floating ground is a reference point for electrical potential in a circuit that is galvanically isolated from the actual ground. Most electrical circuits have a ground that is electrically connected to the Earth, hence the name "ground". When this connection does not exist, the ground is said to be floating. Conductors are also described as having a floating voltage if they are not connected electrically to another non-floating (grounded) conductor.
In a floating circuit, voltages and current flows are induced by electromagnetic fields or charge accumulation within the conductor. This is in contrast to a grounded circuit, where voltages are due to the external potential difference of a power source.
Electrical equipment may be designed with a floating ground for several reasons. One reason is safety. For example, a low-voltage DC power supply, such as a mobile phone charger, is connected to the mains through a transformer. Ensuring that there is no electrical connection between mains voltage and the low-voltage plug makes it much easier to guarantee the safety of the supply. It also allows the charger to connect only to live and neutral, enabling a two-prong plug. Any home appliance with a two-prong plug must have a floating ground.
Another application of floating ground is in electronic test equipment. Suppose you wish to measure a 0.5 V potential difference between two wires that are both approximately 100 V above Earth ground. If your measuring device has to connect to Earth, some of its electronic components must deal with a 100 V potential difference across their terminals. If the whole device floats, then its electronics will only see the 0.5 V difference, allowing more delicate components to be used, which can make more precise measurements.
A floating ground can also help eliminate ground loops, which reduces the noise coupled to the system. However, systems isolated in this manner can drift in potential, and if the transformer is capable of supplying much power, they can be dangerous. This is particularly likely if the floated system is near high-voltage power lines. To reduce the danger of electric shocks, the chassis of the instruments are usually connected separately to Earth ground.
