An electrical interlock is a method for restricting current flow between two or more devices to prevent faults and protect against issues such as short circuits. Interlocks are used in microprocessor architecture to stall a pipeline when a hazard is detected, and in security systems to control access to buildings. In electrical systems, interlocks employ mechanical devices or padlocks to manage the movement of circuit breakers and prevent injuries by restricting direct contact with energized parts of electrical equipment.
Explore related products
What You'll Learn
- Interlocks prevent injuries by stopping direct contact with electrical equipment
- They can be used to restrict current flow between devices
- They are used to prevent non-sequential events from occurring
- Interlocks can be mechanical or electronic
- They are used in microprocessor architecture to stall a pipeline when a hazard is detected
Interlocks prevent injuries by stopping direct contact with electrical equipment
An interlock is a method for restricting action to prevent injuries and protect against various issues. In electrical engineering, interlocks are used to restrict current flow between two or more devices. These types of interlocks use normally open and normally closed contacts to prevent another device from turning on. For example, if you have two relays, CR1 and CR2, and you want to prevent CR1 from turning on if CR2 is on, you would wire the coil in series from CR1 into the normally closed contacts of CR2. This ensures that for CR1 to energize, CR2 must be de-energized. This type of interlock is often used when designing an electrical circuit or system.
Interlocks can also be used as a form of security or access control. In high-security buildings, access control systems may be set up so that the ability to open one door requires another one to be closed first. This type of setup is called a mantrap and can prevent piggybacking or tailgating. Another example of an electrical interlock security system is a trapped key interlock transfer block. In this system, a key is released that can be used to grant access to individual or multiple doors. To obtain the keys, a key must first be inserted and turned. Once the key is turned, the operator may retrieve the remaining keys, which will be used to open other doors. Only once all keys are returned can the original key be removed.
Logical interlocks are another type of interlock used in electrical engineering. These interlocks have an instruction or variable that must be true to allow a result. For example, a pump downstream of a process that needs to be running to start the next pump in line. To do this, the pump's running signal is put in series with the output used for the next pump, ensuring the second pump will not start unless the first pump is running. Logical interlocks are useful when devices are not easily connected electrically or mechanically.
In addition to preventing direct contact with energized parts of electrical equipment, interlocks also allow generator backup power to be provided safely. They do this by preventing main and generator power from being connected simultaneously and by allowing circuit breakers to operate normally without interference in the event of an overload condition. Most interlock devices for electrical systems employ a mechanical device to manage the movement of circuit breakers, and some also allow for the use of padlocks to prevent accidental activation of the main power system without authorization.
