L1, L2, and L3 are designations for the three phases of a three-phase power system. Each phase carries a voltage of 230V to the earth and is 120° out of phase with the other phases, resulting in a voltage of 400V between two phases. In a single-phase system, a single phase and neutral wire are used to deliver 230V to the socket. L1 and L2 are commonly used in electrical wiring and are interchangeable in one-way switches. They are distinguished at the power source, with L1 as the black wire and L2 as the red wire. L3, on the other hand, is typically associated with three-phase systems.
