In the electrical trades, the term line is used to refer to the electrical wires that deliver power from the source to a device. It can also refer to the parts of a circuit that are at full household voltage. In the context of wiring, a line wire is one that feeds power to an electrical device. In a broader sense, it can refer to the part of electric power facilities used to transmit or supply electricity, including lines and associated protective devices and switchgears.
| Characteristics | Values |
|---|---|
| Definition | A wire, conductor, or other means used for the purpose of conveying, transmitting, or distributing electricity. |
| Wire Colour | Line wires are generally black, while load wires are generally red, black, or blue. |
| Function | Carries electricity from the source to a device or appliance. |
| Other Names | Incoming, upstream, supply lines |
| Related Terms | Load refers to the wires that carry power to other devices along the circuit. Also known as outgoing or downstream wires. |
| Tools | Multimeter, Megger, MCEMAX |
Explore related products
What You'll Learn
Line wires are always hot and carrying a current
In electrical wiring, the term ""line" refers to the wires that carry electricity from the source to a device. They are also known as ""supply lines" or "incoming" wires. Line wires are always "hot", meaning they are actively carrying an electrical current. They are the "highway for electrons", allowing current to flow through the circuit.
Line wires are typically black and insulated with colour-coded coatings to prevent accidental contact and ensure proper connections. These coatings indicate the wire's purpose, although there is no standard colour-coding system. A volt pen can be used to determine whether a wire is live, and therefore the line wire.
Line wires are designed to handle the total voltage of an electrical system, typically 120V or 240V in homes. The current flowing through a line wire can vary depending on the connected loads, but it must stay within the wire's ampacity rating to prevent overheating.
In the context of a single device and electrical box, the wires that deliver power into the box are the line wires, while the wires that carry power onwards to other devices are the load wires. The terms "line" and "load" are relative to the location of the device in the circuit. For example, in a series of outlets wired in sequence, the load wire feeds electricity from the first outlet to the remaining boxes on the same line.
