Pelv: Electrical Safety's Secret Weapon Explained

PELV, or Protective Extra-Low Voltage, is a type of electrical system that helps to reduce the risk of electrical shock. It is used in applications where there is a risk of electric shock, such as medical equipment or areas with water. PELV systems have a voltage level of less than 42.4V AC or 60V DC and are meant to be touched by people. They are protected by a safety barrier or isolation device, which helps to prevent accidental contact with higher voltages. PELV circuits are often used in lighting and audio-visual systems where users are expected to touch live parts.
