In electrical terms, PEN is an acronym for Protective Earth and Neutral. It is a means of earthing, commonly used in the UK, where the neutral conductor is also the earth conductor. TN-C-S earthing, also known as PME (Protective Multiple Earthing), is a system where the Neutral and Protective Earth functions are combined in a single PEN conductor. This system is widely used in low-voltage electricity supplies, and it is important to understand the risks and protective measures associated with it, especially in the event of a broken PEN conductor, which can lead to dangerous voltage rises.
Explore related products
What You'll Learn
TN-C-S earthing
In electrical terms, PEN is an acronym for protective earth neutral. It is a combined neutral and protective earth conductor.
Now, onto TN-C-S earthing systems. TN-C-S is a type of earthing arrangement, with the letters indicating certain characteristics of the system. 'T' stands for terra, meaning there is a direct connection to Earth. 'N' stands for neutral, indicating a direct connection to the point on the power supply where it connects to Earth. 'C' and 'S' refer to the use of a combined protective earth and neutral conductor (PEN) and separate protective and neutral conductors, respectively.
In a TN-C-S system, the TN-C (4 wires) system must never be used downstream of the TN-S (5 wires) system. This is because the TN-C-S system uses a combined PEN conductor, which is typically found between the transformer and the consumer installation. Within the installation, separate earth and neutral conductors are used. The 'S' in TN-C-S also refers to the separation of the neutral and earth on the installation side.
One of the dangers of TN-C-S systems is the risk of an open or broken PEN fault, where the supply PEN conductor is severed or significantly corroded. This can lead to a significant rise in voltage-to-Earth, especially if the break occurs upstream of properties on different supply phases. To mitigate this risk, the UK Electricity Safety, Quality and Continuity Regulations 2002 forbid the use of PEN conductors to supply caravans and boats, where simultaneous contact with Earth is highly likely.
In summary, a TN-C-S earthing system is a type of arrangement that uses a combination of direct connections to Earth and separate protective and neutral conductors. While it offers certain advantages, it is important to be aware of the risks associated with open or broken PEN faults and to take the necessary precautions.
