In electrical terms, a 'spur' is an extension of an existing power circuit, which is used to add an extra socket or lighting fixture without needing a complete circuit overhaul. Spurs are generally connected to a ring circuit, which is a common wiring arrangement in many homes. Fused spurs, in particular, are wired connections between an electrical cable and an appliance, bypassing the conventional plug and socket. They are used for higher-power, higher-voltage devices such as ovens, washing machines, and refrigerators. Fused spurs can be switched or unswitched, and they play an important role in safely expanding a home's electrical system while adhering to country-specific standards and regulations.
Explore related products
What You'll Learn
Fused spurs are a type of switch
Fused spurs are available in both switched and unswitched variants. Switched fused spurs include a button to switch off the current to the unit, either within the live line only (single pole spurs) or in both the live and neutral lines (double pole spurs). Double pole fused spurs offer a good level of protection from accidental exposure to electrical current. Unswitched fused spurs, on the other hand, only contain the fuse cage without a switch. Fused spurs with neon lights indicate whether the switch is on or off through the illumination of the lights.
The term gang refers to the length of the electrical box housing spurs and sockets. A '1 gang' model is large enough for a single socket or fused spur, while a '2 gang' model incorporates a pair. Fused spurs can take a 13-amp load and are pre-loaded with a 13-amp fuse, although lower ampage fuses can be used if appropriate. 3 and 5-amp fused spurs are commonly used for light switches.
It is important to note that fused spurs are not the same as residual current device (RCD) sockets, which automatically switch off the live current to protect against electrocution in the event of a fault or short circuit. Fused spurs should only be installed or removed by a qualified electrician as they do not use a conventional plug and socket.
