In electrical terms, TT refers to one of the three primary systems of electrical installation, the other two being TN and IT. The selection criteria for these systems depend on various factors, including regulatory requirements, continuity of service, operating conditions, and network and load types. The TT system is typically used in installations supplied with LV energy and is known for requiring minimal modifications to the existing network.
Explore related products
What You'll Learn
LV energy installations require the TT system
Low voltage (LV) energy installations require the TT system, which is the simplest solution to design and install. This is because it requires the least amount of modification to the existing network, as no additional cables need to be run and no protection devices need to be modified.
The TT system is used in installations supplied directly by the public low-voltage distribution network, typically around 230 Volts for a single-phase connection and 400 Volts for a three-phase connection. LV cables are commonly used in industries such as power stations, power distribution, and railways, where voltages rarely exceed 1100 Volts.
The TT system offers protection through the use of residual current devices (RCDs), which prevent the risk of fire when set to ≤ 500 mA. Each insulation fault results in an interruption in the power supply, but the outage is limited to the faulty circuit due to the installation of RCDs in series or in parallel.
The TT system is particularly useful when load equipment quality is not a design priority, as it helps avoid issues with rapidly decreasing insulation resistance. It is also beneficial in installations with mobile loads, as it can counter the frequent faults caused by sliding contact for bonding exposed conductive parts.
It is important to note that the TT system requires careful consideration of the location of the consumer unit and length of meter tails in relation to the energy meter to minimise the risk of damage and subsequent earth faults. Additionally, the selection of an appropriate RCD for a particular installation should meet specific regulations to ensure effective protection.
