Circuit breakers are essential safety devices in homes and buildings that monitor electrical currents and automatically interrupt the electrical flow in the event of an overload or short circuit. While there are various types of circuit breakers, the three main types are standard, GFCI, and AFCI. Some models have dual functionality, and each handles different amp capacities and operates in different locations in the home. While circuit breakers are built to last for decades, they may sometimes need to be replaced. For example, if there are burn marks around the circuit breaker or it emits a burning smell, it is time to replace it. When it comes to identifying a specific breaker, such as one with a blue handle, it's important to consider the brand and model. In the case of Zinsco R38 and RC38 circuit breakers, a 15-amp breaker typically has a blue handle.
| Characteristics | Values |
|---|---|
| Type | Circuit breaker |
| Function | Standard, GFCI, AFCI |
| Amperage | 15-200 |
| Voltage | 120V/240V or 240V |
| Application | Large appliances such as dryers and water heaters |
| Replacement | Requires a licensed electrician |
| Safety | Interrupts electrical flow in case of overload or short circuit |
| Zinsco R38 | Tandem 20-amp circuit breaker with independent handles |
| Zinsco RC38 | 2-pole half-size circuit breaker with tied handles |
| Color | Blue handles indicate 15-amp amperage |
Explore related products
What You'll Learn
- Blue breakers are dual function, with both AFCI and GFCI capabilities
- Blue breakers are 15-amp Zinsco R38 and RC38 models
- Blue breakers are used to indicate arc fault + ground fault
- Blue breakers are safe to use, but can be replaced if showing burn marks
- Blue breakers are a common feature of Bryant breaker panels
Blue breakers are dual function, with both AFCI and GFCI capabilities
In electrical wiring, blue breakers are dual-function circuit breakers with both arc fault circuit interruption (AFCI) and ground fault circuit interruption (GFCI) capabilities. AFCI breakers protect against fires caused by arcing faults in the circuit wiring, whereas GFCI breakers protect against electric shock by interrupting the current to a circuit when it detects a loss of current. This loss of current may be due to an overload, short circuit, or a line-to-ground fault, where an unwanted path forms between an electrical current and a grounded element.
Dual-function circuit breakers are essential in providing comprehensive protection against electrical hazards. They are especially useful in areas where both fire and shock risks are present, such as finished basements, hallways, closets, kitchens, laundry areas, and bedrooms.
The colour-coding of circuit breakers is important for quick identification and replacement. In the case of Zinsco circuit breakers, blue handles indicate a 15-amp capacity. However, it is important to note that the colour-coding system may vary across different brands or models of circuit breakers. Therefore, it is always advisable to refer to the specific manufacturer's guidelines or seek the assistance of a licensed electrician.
While colour can be a helpful indicator, it is not the only factor to consider when identifying or replacing a circuit breaker. Other factors, such as the model, type, and ampere rating, are also crucial in ensuring the proper functioning and safety of the electrical system. It is recommended to consult a qualified electrician or refer to the specific guidelines provided by the manufacturer for the particular breaker in question.
