A 4-pole electrical connection is a type of circuit breaker that isolates three phases and the neutral wire of a three-phase line. It is used in multi-incomer power feeding systems to isolate the neutral wires of incoming power sources from the neutral wire of the incomer power in use. In comparison, a 3-pole connection isolates only three phases and is used in a three-phase electrical system. The use of a 3-pole or 4-pole connection depends on system protection and configuration.
Explore related products
What You'll Learn
Breakers are classified by the number of poles
A single-pole breaker provides 120 volts, 15-20 amps, and has one hot wire and one neutral wire. When there is an overload in a single-pole breaker’s circuit, only that particular breaker trips. Double-pole breakers, on the other hand, provide 240 volts, 20-60 amps, and have two hot wires that share one neutral wire. Both breakers will trip if there is a short circuit on either of the hot wires.
Three-pole breakers, or TP breakers, are used in three-phase, four-wire systems. They are used to connect three wires for a three-phase system. In the case of four-pole breakers, protection is applied to the current flow through all poles. When the breaker trips or is manually opened, all poles are disconnected. Four-pole breakers are used when the system has two alternative sources and a changeover to a standby generator is required in the event of a power failure.
In some cases, a four-pole breaker may be created by paralleling 100-ampere breakers. Each leg of the service is connected to a pair of 100-ampere single-pole breakers in parallel, allowing the current to be divided equally between the breakers.
