A closed-loop electrical circuit is a continuous path that allows electric charges to flow from an active energy source to the connected load or other components. In other words, it is a complete circuit with no interruptions to stop the flow of power. A closed-loop circuit is often compared to a road that crosses a river via a bridge, as the bridge allows a car to move down a road and return to the other side. A closed-loop circuit works in a similar way, allowing electrical energy (electrons) to flow and move. A closed-loop circuit is the opposite of an open-loop circuit, where there is no complete path for energy to travel from the source to the load.
| Characteristics | Values |
|---|---|
| Definition | A closed-loop electrical circuit is a complete pathway for active energy to travel from the source to the load. |
| Current | Current flows in a loop from positive to negative charge particles. |
| Switch | A closed switch allows current to pass through, while an open switch does not. |
| Open Loop vs. Closed Loop | Open-loop systems are non-feedback systems, while closed-loop systems use feedback to reduce errors and bring the output back to the desired value. |
| Examples of Closed Loop Systems | Home thermostat, cruise control in a car, building HVAC system in a data center, computer room air handlers (CRAHs) |
Explore related products
What You'll Learn
A closed circuit is a continuous loop
To create a closed circuit, we need conducting materials or conductors (like copper), an active voltage source device (like a battery), and a full path or circuit for the electric current to flow. A switch can be used to make (ON) and break (OFF) the circuit, with circuit breakers and fuses performing this function in a power system. When the switch is closed, the circuit is complete, and the current can flow.
In contrast, an open circuit creates an insufficient channel for active energy to pass from the source to the load. Current does not flow in an open circuit, and it is represented by the symbol ‘( )’. A closed circuit, on the other hand, creates a continuous loop for current to flow, and it is symbolized by ‘(.
Closed-loop systems can be found in various applications, such as a home thermostat, cruise control in a car, and building heating, ventilation, and air conditioning systems. These systems use feedback control to maintain a desired state or set point without human interaction. They automatically regulate the system by monitoring the output and comparing it to the desired output to reduce errors and bring the system back to its desired state.
