In electronics, a dividing point refers to a voltage divider or potential divider, which is a basic circuit used in electronic circuit design. It is a simple configuration that uses very few electronic components and enables a lower voltage to be created from a larger one. The voltage divider is a fundamental element of any electronics circuit design and is widely used because it provides an important function. It consists of two resistors in series, connected between the input voltage and zero volts or ground. The junction between the two resistors then has a small proportion of the input voltage appearing across it.
In telephony, the term dividing point may also refer to the demarcation point, which is the point at which the public switched telephone network ends and connects with the customer's on-premises wiring. This point determines who is responsible for the installation and maintenance of wiring and equipment.
Characteristics and Values of a Dividing Point in Electrical Engineering
| Characteristics | Values |
|---|---|
| Definition | A voltage divider, or potential divider circuit, is a basic circuit used in electronic circuit design to provide a reduced voltage from a larger one. |
| Circuit | Consists of two resistors in series, with the input voltage applied across them. |
| Function | Divides the input voltage to provide a lower voltage for use in the circuit. |
| Equation | The output voltage is directly proportional to the input voltage and the ratio of the resistors' values. |
| Applications | Widely used in electronic circuit design, especially where a lower voltage is required. |
| Advantages | Requires very few electronic components, making it simple and cost-effective. |
| Flexibility | By manipulating resistor values, a specific output voltage can be achieved from a fixed input voltage. |
| Limitations | The presence of a resistance across the output can alter the operation of the circuit. |
| Examples | Used in potentiometers, accelerometers, gyroscopes, and microcontrollers. |
| Standards | Must comply with electrical standards and regulations, such as the US National Electric Code. |
Explore related products
What You'll Learn
The Demarcation Point in telephony
In the context of telephony, the demarcation point is the point at which the public switched telephone network ends and connects with the customer's on-premises wiring. It is a critical boundary in network infrastructure that determines service responsibilities and plays a key role in troubleshooting network issues. The demarcation point is also referred to as the "demarc point", "network boundary point", or "network demarcation point".
The demarcation point varies between countries and building types and has changed over time. In its simplest form, it is a junction block where telephone extensions join to connect to the network. This junction block typically includes a lightning arrester, which requires a wire to ground. In multi-line installations, such as businesses or apartment buildings, the demarcation point may be a punch-down block.
In the United States, the modern demarcation point is defined by FCC rules (47 C.F.R. Part 68) to enable the safe connection of third-party telephone customer-premises equipment and wiring to the Public Switched Telephone Network (PSTN). The physical and electrical interconnection is called the demarcation point, which includes one or more customer-accessible jack interfaces. The modern demarcation point is typically the Network Interface Device (NID) or Intelligent Network Interface Device (INID), also known as a "smartjack". The NID is owned by the telco.
The demarcation point has a user-accessible RJ-11 jack (a "test jack" or "demarcation jack"), which is connected directly to the telephone network. When the loop is disconnected, the on-premises wiring is isolated from the telephone network, and the customer can directly connect a telephone to the network via the jack to assist in determining the location of a wiring fault. In most cases, everything up to and including the demarcation point is owned by the carrier, and everything past it is owned by the property owner.
