A one-line drawing, also known as a single-line diagram (SLD), is a simplified visual representation of an electrical power system. It uses standard symbols and lines to represent the nodes and connections in the system, with the power source displayed at the top of the diagram. This allows for the easy visualisation of the power path downstream from node to node. One-line drawings are essential tools in electrical engineering, providing a clear overview of electrical power systems and facilitating system design, maintenance, and troubleshooting. They are also useful for planning lockout/tagout procedures and ensuring system safety.
| Characteristics | Values |
|---|---|
| Purpose | To provide an easy-to-understand schematic for electrical engineers and technicians, facilitating system design, maintenance, and troubleshooting |
| Representation | A simplified representation of an electrical system |
| Lines | A single line in the diagram typically corresponds to more than one physical conductor |
| Power Source | Displayed at the top of the diagram |
| Symbols | Standard symbols are used to denote the various components and connections in a power system |
| Interconnections | Visualize and see details of your utility feed, generator and fuel tanks, transformers, load devices, UPS units, AC panels, floor PDUs, DC power plants, and DC bays |
| Electrical Characteristics | Track key electrical characteristics for all the facility items in your power chain |
| Breakers | Track all draw-out breakers and disconnect switches |
| Nodes | Include utility feed, generators and fuel tanks, transformers, switchgears, switchboards, automatic transfer switches, uninterruptible power supply units, and floor power distribution units |
| Diagram Review | CSA Z463 recommends a single-line diagram be reviewed after 5 years or when there has been a significant change |
Explore related products
What You'll Learn
- A one-line drawing is a simplified representation of an electrical system
- They are used to visualise power distribution and control circuits
- They are useful for planning, troubleshooting, and reducing potential outages
- They use standard symbols to represent electrical components and connections
- They are essential tools for electrical engineers and technicians
A one-line drawing is a simplified representation of an electrical system
A one-line drawing, also known as a single-line diagram (SLD), is a simplified representation of an electrical system. It is a form of block diagram that uses standard symbols and lines to represent the components, connections, and electrical flow paths in a power system. This allows for a clear and concise overview of the system, making it easier to design, analyse, and troubleshoot electrical circuits.
In a one-line drawing, a single line typically corresponds to more than one physical conductor. In a direct current system, the line includes both the supply and return paths, while in a three-phase system, the line represents all three phases. This simplification allows for a more straightforward understanding of the system, especially when compared to the more complex traditional static diagrams.
The primary purpose of a one-line drawing is to provide a schematic that is easy for electrical engineers and technicians to interpret. This helps facilitate system design, maintenance, and troubleshooting. For example, in a data centre, a one-line drawing can be used to visualise the power distribution system, improve planning and troubleshooting, ensure redundancy, and reduce potential outages.
The nodes of a data centre's one-line drawing typically include the utility feed, generators, fuel tanks, transformers, switchgears, switchboards, automatic transfer switches (ATS), uninterruptible power supply (UPS) units, and floor power distribution units (PDUs). These nodes are connected by lines, with the power source usually displayed at the top of the diagram so that the power path can be easily followed downstream.
One-line drawings can be created using specialised software, such as AutoCAD Electrical or ETAP, which provide comprehensive tools and symbol libraries for creating accurate and professional diagrams. It is important to keep these diagrams up-to-date, as per recommendations, to ensure their effectiveness in everyday operations and maintenance.
