A shunt is a device that diverts electrical current in a circuit to a different point, creating a low-resistance path. Shunts are commonly used in a variety of applications, including power distribution systems, electrical measurement systems, and battery monitors. They are particularly useful for measuring large currents that cannot be directly measured by an ammeter. By placing a shunt in parallel with the ammeter, the current can be diverted through the shunt, and the voltage drop across the shunt can be used to calculate the current using Ohm's law. Shunts also have applications in lightning arresters and overload protection circuits.
Explore related products
Shunt resistors
A shunt resistor is a type of device that passes electrical current around another device. Shunt resistors are used to measure electric current, both alternating and direct. This is done by measuring the voltage drop across the resistor. The voltage across the shunt is proportional to the current flowing through it, and so the measured voltage can be scaled to directly display the current value.
The placement of the shunt resistor in the circuit is important. When the circuit shares a common ground with the measurement device, the shunt is often placed as close to the ground as possible to protect the ammeter from high common-mode voltage. If the shunt is placed in the ungrounded leg, it must be isolated from the ground or include a voltage divider or an isolation amplifier to protect the instrument.
