A wild leg is a term used in electrical systems to describe a specific type of configuration known as a high-leg delta or open-delta high-leg system. This type of system typically involves three-phase power with four wires, where one of the phases has a higher voltage to ground compared to the other phases. It is commonly found in older manufacturing facilities with three-phase motor loads and some single-phase lighting and plug loads. The high-leg or wild leg phase is usually labelled as Phase B or, in some cases, Phase C to accommodate utility meter configurations. These systems can provide various voltages, such as 240/120V or 208Y/120V, and have specific requirements for panelboards, switchboards, and switchgear to ensure they are rated for the supplied voltage.
Explore related products
What You'll Learn
- Lagging current is when the current is delayed in time with respect to the voltage in an AC circuit
- Leading current is when the current reaches its maximum value up to 90° before the voltage
- Lagging power factor means the impedance in the circuit is inductive, causing the phase current to lag the phase voltage
- Leading power factor means the current is advanced in phase with respect to the voltage
- Wire lag in wire electrical discharge machining (WEDM) is a phenomenon that influences machining performance
Lagging current is when the current is delayed in time with respect to the voltage in an AC circuit
In electrical engineering, the terms "leading" and "lagging" refer to the relationship between current and voltage in an alternating current (AC) circuit. Leading and lagging currents are phenomena that occur due to alternating currents, where the values of voltage and current vary sinusoidally.
Lagging current specifically refers to a delay in the current with respect to the voltage. In other words, the current waveform is behind the voltage waveform. This is formally defined as "an alternating current that reaches its maximum value up to 90 degrees later than the voltage that produces it". In circuits with primarily inductive loads, the current lags the voltage because the induced electromotive force, caused by a change in the magnetic flux linking the coils of an inductor, is responsible for the flow of current.
The power factor of an AC system, which is the expression of energy efficiency, is closely related to the concept of leading and lagging currents. The power factor is defined as the ratio of active power (in Watts) to apparent power (in VA). Lagging power factor occurs when the load current lags behind the supply voltage, indicating that the load is inductive and will consume reactive power. Capacitive loads are used to correct a lagging power factor.
Leading current, on the other hand, is when the current reaches its maximum value up to 90 degrees ahead of the voltage. In this case, the current leads the voltage. An inductive load is used to correct the leading power factor.
Understanding the concepts of leading and lagging currents is crucial in electrical engineering, especially when dealing with AC circuits and power factors.
