A wild leg in electricity is a term used to refer to a type of electrical service known as a high-leg delta or wild-leg delta. It is a three-phase power configuration where one of the phases, typically labelled as Phase B, has a higher voltage compared to the other two phases when measured to neutral. This phase with an elevated voltage is referred to as the high leg or wild leg. In a four-wire delta system, the voltage between any two phases is 240V, but the voltage between Phase B and the neutral point is 208V, making it the wild leg. This type of electrical service is commonly found in older manufacturing facilities and areas with ageing electrical infrastructure.
| Characteristics | Values |
|---|---|
| Type of electrical service | Four-wire delta (4WD) |
| Type of load | Three-phase delta service with a center-tap on one of the transformer windings to create a neutral for single-phase loads |
| Voltage | 240 volt, three-phase, three-wire delta service |
| Phase | B phase, also known as the "high leg" or "wild leg" |
| Voltage between phases | 240V |
| Voltage between phase and neutral point | 208V |
| Safety | Requires special markings or labeling to alert technicians and users of the increased voltage and the need for extra caution |
| Use case | Commonly used in older manufacturing facilities with mostly three-phase motor loads and some 120-volt single-phase lighting and plug loads |
Explore related products
What You'll Learn
- The wild leg is also known as the high leg, stinger leg, bastard leg, etc
- It is a three-phase, 4-wire, delta-connected system
- It is usually identified as Phase B, but can be labelled as Phase C
- It is marked orange to alert users of the increased voltage and the need for caution
- It is supplied using 240 V line-to-line and 120 V line-to-neutral
The wild leg is also known as the high leg, stinger leg, bastard leg, etc
The "wild leg" is a term used to refer to a specific type of electrical system configuration known as a "high-leg delta". It is a three-phase power configuration where the centre point of one phase is grounded, resulting in three ungrounded phase conductors and a neutral. This configuration is commonly used in older manufacturing facilities with mostly three-phase motor loads and some single-phase lighting and plug loads.
The "wild leg" is also referred to as the "high leg", indicating that it has a higher voltage compared to the other phases. This higher voltage poses a greater safety risk if not handled properly, and electrical codes often require special markings or labelling to alert technicians and users. The term "wild leg" likely originated from the early days of electrical systems when this higher-voltage phase was considered more unpredictable or "wild".
The "wild leg" is also known as the "stinger leg", a term that may come from the potential danger of the high voltage. Additionally, it has been referred to as the "bastard leg", possibly due to the unconventional nature of having one phase with a higher voltage. These terms are used to distinguish this phase from the others and to indicate its unique characteristics and potential hazards.
The "wild leg" or "high leg" is usually labelled as "Phase B" to indicate its higher voltage. However, with the change in the 2008 NEC (National Electrical Code), it can now also be labelled as "Phase C" in certain situations, such as when metering is part of the switchboard or panel board. This change provides more flexibility in the system configuration while still ensuring proper identification and safety measures.
The "wild leg" configuration offers advantages such as providing a higher line-to-line voltage than typical three-phase services, while also offering a sufficient line-to-neutral voltage for connecting appliances and lighting. This dual capability allows for efficient power utilisation and can result in reduced current draw, requiring smaller wire and breaker sizes.
