Shunts are electrical devices that measure the flow of electrical current. They are commonly used in ammeters and digital multimeters to accurately measure electrical current, playing a critical role in various electrical systems. Shunts are also used in battery systems to monitor the energy flowing out of a battery. They are usually built into the negative side of a battery terminal. The term “shunt resistor” is used to describe a resistor that passes current around a load. Shunt resistors are used to measure high currents with low levels of associated resistance.
| Characteristics | Values |
|---|---|
| Definition | A device that passes electrical current around another device |
| Other names | Shunt resistors, ammeter shunts, current shunt resistors |
| Function | Measures electric current, both alternating and direct |
| Types | Shunt resistor, shunt capacitor, shunt diode |
| Used in | Ammeters, digital multimeters, battery systems, over-current protection, 4-20mA systems, battery charging, H-bridge motor control |
| Placement | Close to the ground, near the battery |
| Advantage | Measures current in real-time, providing a higher degree of accuracy |
Explore related products
What You'll Learn
Shunts are made of resistors
Shunts are electrical devices that create a low-resistance path for an electrical current, allowing it to flow to an alternative point in the circuit. This is achieved by placing a resistor in parallel with an ammeter, resulting in a division of current and enabling the measurement of amperage levels. Shunts are commonly used to measure high currents with low levels of associated resistance.
Shunts are often constructed with a low resistance value, typically in the milliohm range, to ensure they have minimal impact on the overall circuit's behaviour. This allows for a small portion of the current to be diverted through the shunt resistor, where it can be accurately measured. By understanding the voltage drop across the shunt and the resistance of the shunt, the current can be calculated using Ohm's law.
Shunts are widely used in ammeters and digital multimeters to measure electrical current accurately. They are particularly useful in battery systems, where they help monitor the energy flowing out of a battery and provide a fuel gauge-like function. Shunts are typically placed on the negative lead near the batteries to record all currents flowing in and out before branching off into other circuits.
Shunts also have applications in over-current protection, 4-20mA systems, battery charging, and H-bridge motor control. They are essential for engineers and technicians to monitor and control current levels in various applications, from small electronic circuits to high-power electrical distribution networks.
