Electro-hydraulic proportional valves are electrically operated valves that control the flow of hydraulic fluid to an actuator. They are used to adjust flow, pressure, and direction. The increasing use of electronics to control hydraulic systems has led to greater interest in these valves. There are two main types of electro-hydraulic proportional valves: servo valves and servo-proportional valves. These valves use an electronic signal to provide precise control of position, velocity, and force.
Explore related products
What You'll Learn
- Electro-hydraulic servo valves (EHSV) are electrically operated
- They control hydraulic fluid flow to an actuator
- They are used for precise control of position, velocity, pressure and force
- Proportional valves use electrical feedback, often an LVDT (linear variable differential transformer)
- They have a large input power range, from several hundred mA to over 1 amp
Electro-hydraulic servo valves (EHSV) are electrically operated
EHSVs use an electronic signal to control the movement of a hydraulic cylinder smoothly and precisely. This signal can be either analogue or digital, and it results in a corresponding set of movements in the cylinder. The valves are designed to respond to the amount of current supplied to the solenoid, determining the direction and flow rate of the hydraulic fluid.
EHSVs are known for their accuracy and precision. They have a smaller input power range, typically tens of mA, compared to proportional valves, which operate with input power ranging from several hundred mA to over 1 amp. This lower input power grants them greater control accuracy with lower hysteresis.
In the event of a loss of electrical power, EHSV centering springs return the valve spool to the center position. The valve solenoids can be driven by a variable current power supply or external power amplifier cards designed to maximize valve performance.
EHSVs are commonly used in applications where precise control of position, velocity, and force is required. They are often employed in industrial settings, heavy-duty equipment, and systems requiring accurate motion control. By using electronic signals, EHSVs offer a level of precision that meets the demands of modern hydraulic systems.
