Electric power is the rate of electrical energy transfer by an electric circuit per unit of time. The unit of electric power is the watt, defined as one joule per second. In alternating current (AC) circuits, the direction of the voltage and current periodically reverses. Circuits can either function in an idle, active, or maximum state of power consumption. Power is the function of current and voltage, and the current is a varying factor in determining power. The amount of electrical energy consumed by a circuit over a period of time is measured in watt-hours.
| Characteristics | Values |
|---|---|
| Unit of energy | Kilowatt-hours |
| Unit of power | Watt |
| Power consumption in steady-state circuit | No increase in kinetic energy, energy is consumed through resistance |
| Power consumption in non-steady-state circuit | Voltage source with no resistance, increasing current |
| Power consumption in alternating current (AC) circuits | Positive or negative, depending on the direction of power flow |
| Power consumption in circuits with energy storage | Some energy is temporarily stored and returned to the circuit, resulting in periodic reversals of energy flow direction |
| Power consumption in resistors | Voltage drop over the resistor is equal to the battery voltage drop |
| Power consumption in ideal voltage sources | No energy loss, raises the potential of charges in the circuit |
Explore related products
What You'll Learn
Electric power is the rate of electrical energy transfer
Electric power is the rate at which electrical energy is transferred by a circuit per unit of time. It is measured in watts (W), and its equation is given as Power = work done ÷ time taken. The potential difference, or voltage, of a supply is a measure of the energy given to the charge carriers in a circuit, and it is measured in volts (V). The current, or the movement of electric charges, is measured in amps (A). One watt is equal to one joule per second (J/s).
The rate of energy transfer in a circuit is determined by the potential difference or voltage, and the current. Electrical power can be delivered as a low current with a high voltage or a high current with low voltage. A high current will have a much higher heating effect on the transmission wires than a low current. Hence, transmitting energy at a high voltage and low current will keep the wires cooler and waste less energy.
The power consumed by a circuit is dependent on the state of power consumption. Circuits can function in an idle, active, or maximum state of power consumption. For example, an alarm controller remains in sleep mode, with a minimum current until it is activated by an interrupt. It then enters an active state, where it consumes more power by reading biometric thumbprints and comparing them within its database. Upon validation, it triggers the relays, activates buzzers, and communicates with the central server. These simultaneous actions result in the maximum power consumption of the device.
In circuits with energy storage elements, some of the energy flowing into passive components is stored temporarily and returned to the circuit each cycle. This results in periodic reversals of the direction of energy flow. The portion of energy flow (power) that, averaged over a complete cycle of the AC waveform, results in a net transfer of energy in one direction is known as real power or active power. The amplitude of that portion of energy flow (power) that results in no net transfer of energy but instead oscillates between the source and load in each cycle due to stored energy, is known as the absolute value of reactive power. The product of the RMS value of the voltage wave and the current wave is known as apparent power. The ratio of real power to apparent power is called the power factor.
