Synchros are a type of transducer that transforms the angular position of a shaft into an electric signal. They are used as error detectors and rotary position sensors. The electrical zero position is used as a reference for specifying the angular position of the rotor. The input to the synchro transmitter is the angular position of its rotor shaft, and the output is a set of three stator coil-to-coil voltages. By measuring and identifying these voltages, the angular position of the rotor can be determined. The electrical zero position of the rotor is important for the functioning of the synchro system, as it serves as a reference point for determining the rotor's angular position.
| Characteristics | Values |
|---|---|
| Definition | A synchro is a type of transducer that transforms the angular position of the shaft into an electric signal |
| Types | Control type synchro, Torque transmission type synchro |
| Function | Error detector, Rotary position sensor |
| Synchro pair | Synchro transmitter, Synchro control transformer |
| Electrical zero position | Used as a reference for specifying the angular position of the rotor |
| Input | Angular position of its rotor shaft |
| Output | Set of three stator coil-to-coil voltages |
| Construction | Similar to the synchro transmitter except for the shape of the rotor |
| Rotor of control transformer | Cylindrical shape to ensure a uniform air gap |
| Coarse setting | Device is zeroed on the 0º position |
| Fine setting | Aligning two marks on the synchro |
| Frequency | Terrestrial synchros: 50 or 60 Hz, Marine/aeronautical synchros: 400 Hz |
Explore related products
$12.99
What You'll Learn
- The electrical zero position is used as a reference for specifying the rotor's angular position
- The transmitter rotor's electrical zero position and the control transformer rotor's null position
- The angular displacement between the rotor axes of the transmitter and controller
- The electrical output from the rotor is proportional to the sine of the difference between the rotor angular position and electrical input angle
- The zero position of the rotor is used as a reference for determining the rotor angular position
The electrical zero position is used as a reference for specifying the rotor's angular position
The electrical zero position is a critical reference point for determining the angular position of a rotor in a synchro system. Synchros are devices that convert the angular position of a shaft into an electric signal, with applications in error detection and rotary position sensing.
The electrical zero position serves as a baseline for measuring and specifying the angular position of the rotor. By establishing this zero position, it becomes possible to accurately identify the rotor's angular displacement at any given time. This reference point is essential for the precise control and operation of the system.
In a synchro system, the angular position of the rotor shaft is the input, and the output is a set of three stator coil-to-coil voltages. These voltages are measured and identified at the stator terminals, allowing for the determination of the rotor's angular position. The electrical zero position is a key aspect of this process, as it provides a reference point from which the voltages and, subsequently, the angular position can be calculated.
The synchro transmitter and the synchro control transformer, also known as the synchro pair, play a crucial role in this process. The transmitter's shaft rotates, sending information, while the receiver's shaft operates a dial or light mechanical load. The electrical zero position of the transmitter's rotor is significant because it corresponds to the null position of the control transformer's rotor, where the output voltage on the rotor winding is zero. This relationship between the electrical zero position and the null position ensures the accurate alignment of the shafts and the proper functioning of the synchro system.
The electrical zero position is established through a two-step process. The first step is the coarse or approximate setting, ensuring the device is zeroed on the 0° position. The second step is the fine setting, making any necessary adjustments for precise alignment. By following these steps, the electrical zero position is accurately determined, providing a reliable reference for specifying the rotor's angular position.
