In electrical engineering, NO and NC are terms used to describe the states of a contactor when the voltage in an electrical system is off. NO stands for normally open, which means that the wire connected to this contact will normally be open or off, and the current will not flow when the relay is deactivated. NC, on the other hand, stands for normally closed, which means that the contactor will close a circuit in the event of a voltage drop or power failure. These terms are essential for designing circuits and writing PLC programs that control various functions, providing the foundation for building logic by allowing users to specify how a system behaves under different conditions.
| Characteristics | Values |
|---|---|
| Full Form | NO: Normally Open |
| NC: Normally Closed | |
| Description | When the relay coil is not energised, the switch contact in the NO system is open or disconnected. |
| When the relay coil is not energised, the switch contact in the NC system is closed or connected. | |
| Use Cases | NO is used in electrical systems where, for safety reasons, you want to be sure that the contactor opens when the power is cut in the system in case of a power failure. |
| NC is used when you want to be sure that the contactor closes a circuit in the event of a voltage drop, such as a power failure, to drain the system of energy to earth. | |
| NO and NC are used for any mechanical switch, not just electrically-actuated ones. They are also used with switches, in addition to relays, with the same meanings. |
Explore related products
What You'll Learn
- Normally Open (NO) and Normally Closed (NC) are electrical engineering terms
- NO and NC are used for any mechanical switch, including toggle switches
- NO and NC are essential for designing circuits and writing PLC programs
- NO and NC contacts work in opposite ways: when one is working, the other is off
- NO is used for safety, while NC is used to drain the system of energy
Normally Open (NO) and Normally Closed (NC) are electrical engineering terms
Normally Open (NO) and Normally Closed (NC) are terms used in electrical engineering to describe the state of a contactor when the voltage in an electrical system is off. In an electrical relay system, there are two types of contacts: Normally Open (NO) and Normally Closed (NC). This is because the current path can either be open or closed.
Normally Open (NO) contacts are used in electrical systems where, for safety reasons, it is important to ensure that the contactor opens when the power is cut or in the event of a power failure. When the relay is activated, the circuit is connected, and the current flows. When the relay is inactive, the circuit is disconnected, and the current does not flow.
Normally Closed (NC) contacts are used when it is necessary to ensure that the contactor closes a circuit in the event of a voltage drop or power failure, allowing the system to be drained of energy. When the relay is activated, the circuit is disconnected. When the relay is inactive, the circuit is connected.
Both NO and NC contacts are essential for designing circuits and writing PLC programs that control various functions. They provide the foundation for building logic by allowing for the specification of system behaviour under different conditions.
It is important to note that NO and NC can be used with switches in addition to relays, and they have the same meanings in the context of mechanical switches.
