Electro-pneumatic systems combine electrical and pneumatic effects, using electric power to control pneumatic action. In other words, they integrate electrical and pneumatic technologies into a single system, where the signal/control medium is electrical and the working medium is compressed air. Electro-pneumatic systems are used in pipe organs, where air pressure, controlled by an electric current, opens and closes valves within wind chests, allowing the pipes to speak. They are also used in robotics and automation, where they enable the control of the flow of compressed air with a push-button.
Explore related products
What You'll Learn
- Electro-pneumatic systems are a combination of electrical and pneumatic effects
- They are used to control the flow of compressed air with a push-button
- Electro-pneumatic action allows for the construction of new pipe organs without any physical linkages
- Electro-pneumatic equipment runs off standard voltages, so they can be operated off regular mains current
- Electro-pneumatic relays have been replaced by electronic and computerized control systems
Electro-pneumatic systems are a combination of electrical and pneumatic effects
Electro-pneumatic systems are used to control the flow of compressed air with electrical inputs, such as the push of a button. They are often used to automate or rework existing installations, providing greater control over pneumatic devices. For example, solenoid valves are a type of valve that utilises electrical coil windings to actuate a valve's moving components. The electrical current passed through a coil of wire within the solenoid valve produces a magnetic field, which attracts an iron armature, operating the valve.
In electro-pneumatic systems, the electrical side is responsible for starting and stopping processes and monitoring the system's status. This is achieved through devices like relays, solenoid valves, limit switches, and PLCs (Programmable Logic Controllers). Relays, for instance, can be used to automatically activate pneumatic action when energised by an electrical signal, opening or closing contacts.
PLCs, on the other hand, can handle multiple logical inputs and control outputs, integrating functions like timing, sequential operations, alarming, and remote visibility. They can determine when to activate control valves based on input transitions, providing a high degree of control over the flow of air.
Overall, electro-pneumatic systems offer a combination of electrical and pneumatic effects, providing advantages such as increased control, flexibility, and the ability to integrate various components and functions.
