In electrical engineering, a feeder is a dedicated line of cables that carry electricity from a power station or substation to the end user, usually through an intermediate tapping point. Feeders are a crucial component in the distribution of electricity, connecting the sources of electricity (power stations and substations) with the end user (homes and businesses). They are also important in public transportation, ensuring connectivity between high-capacity routes and more localized departure and destination points.
Characteristics and Values of Electrical Feeders
| Characteristics | Values |
|---|---|
| Definition | All circuit conductors between the service equipment, the source of a separately derived system, or other power supply sources and the final branch-circuit overcurrent device |
| Function | To deliver electricity within a house or building |
| Connection | Connects the source of power, such as a power station or substation, to the end user |
| Safety | Provides a safe means for electricity distribution |
| Reliability | Ensures reliability of electricity supply |
| Distribution | Distributes electricity within a given area |
| Components | Circuit breakers, transformers, distribution points, and other related components |
| Type | Feeder lines can be either underground or overhead depending on the type and local regulations |
| Identification | Standard feeder identification methods allow qualified persons to quickly identify the phase and voltage of feeder conductors |
| Use Cases | Commonly used in commercial projects with multiple distribution points and in public transportation systems |
