SMDB stands for Sub Main Distribution Board. It is an electrical switchgear that is used to distribute current from a single source of supply to various circuits. SMDBs are extremely economical for reducing power cabling costs and are generally installed at load centers. They are sheet steel enclosed with powder coating and can be designed for cabinet (wall) or feeder pillar (floor) mounting.
Sub Main Distribution Boards (SMDB)
| Characteristics | Values |
|---|---|
| Description | A type of Distribution Board (DB) |
| Use | To distribute current from a single source of supply to various circuits |
| Installation | Generally at load centers |
| Design | Sheet steel enclosed with Powder coating In Cabinet (Wall mounting) or Feeder Pillar (Floor mounting) |
| Type | Outdoor or Indoor |
| Space | Ample space for ease of cable Termination |
| Customization | Customized to user requirements |
| Cost | Economical for reducing Power cabling costs |
Explore related products
$55.63
What You'll Learn
Sub Main Distribution Boards (SMDB) are used to supply electricity to panels
Sub Main Distribution Boards (SMDB) are an extremely cost-effective way of reducing power cabling costs. They are generally installed at load centres and are sheet steel enclosed with powder coating in a cabinet (wall-mounted) or feeder pillar (floor-mounted) design. SMDBs are used to supply electricity to panels. They can be customised to user requirements and have ample space to facilitate cable termination.
SMDBs are suitable for both indoor and outdoor use and can be adapted to the available location. They are often used in conjunction with Power Distribution Boards (PDB) or Main Distribution Boards (MDB), which have a main incomer of up to 2500A or 4000A and various outgoing feeders. The PDB or MDB can be designed with suitable cable alleys to terminate cables from the top, bottom, or sides.
The electrical wiring within an SMDB distributes current from a single source of supply to various circuits. These circuits are arranged inside an enclosure, which is typically made of sheet steel with a powder coating. This enclosure can be customised to the user's needs and can be mounted on a wall or floor, depending on the design.
SMDBs are an essential component of electrical systems, particularly in managing and distributing power to panels and other equipment. They offer a flexible and cost-effective solution for a range of applications, from industrial automation to energy auditing. By using SMDBs, users can benefit from reduced cabling costs and a more efficient power distribution system.
