In the electrical trades, a pigtail is a slang term for a junction of a group of conductors, where a lead conductor is added to connect that junction to a device or fixture. Pigtails are short wires used to connect multiple wires to a single point or device, ensuring a secure connection by combining wires with a wire connector. They are used in electrical wiring to connect two or more wires together, often to join a device, such as a light switch, to a power source. Pigtails are most commonly used to ground a switch or receptacle and can also be used to connect a light switch to two or more fixtures.
Explore related products
![[ETL Listed] Miady Short Power Extension Cord Outlet Saver, 16AWG/13A, 3 Prong (10 Pack, Black, 8 Inch)](https://m.media-amazon.com/images/I/61bH4dGoRVL._AC_UL320_.jpg)
What You'll Learn
- Pigtails are used to connect multiple wires to a single point or device
- They ensure a secure connection by combining wires with a wire connector
- Pigtails are used to ground a switch or receptacle
- They allow power to keep flowing downstream to the rest of the circuit, even if one device fails
- Pigtails are usually made of copper wire
Pigtails are used to connect multiple wires to a single point or device
Pigtails are an essential component of electrical wiring projects, used to connect multiple wires to a single point or device. They are short wires, typically made of copper, that facilitate the transfer of the connection point from a receptacle to a wire nut or connector. This allows for a continuous circuit that is uninterrupted when devices are removed or replaced.
Pigtails are particularly useful when there are more than one or two sets of conductors in an electrical box. They simplify connections in crowded electrical boxes and reduce the risk of loose or faulty connections. This is because, instead of attaching multiple wires directly to a single screw or terminal, each wire is connected securely to the appropriate terminal via the pigtail, reducing strain on the terminals.
The use of pigtails also improves safety and flexibility in electrical systems. They minimise the risk of loose or overheating connections and act as a failsafe, allowing power to continue flowing downstream to the rest of the circuit even if one device fails. Pigtails also simplify future repairs and upgrades. When a device or outlet needs to be replaced, the pigtail allows for the disconnection and reconnection of components without disturbing the rest of the wiring.
Pigtails are commonly used to ground a switch or receptacle, with green grounding pigtails linking the metal box and device to a circuit's grounding wires. They are also used to connect light switches to two or more fixtures. When creating a pigtail connection, it is important to ensure that the pigtail wire matches the wire gauge of the circuit wires so that it can handle the current. The National Electric Code requires pigtail wires to be at least six inches long.
