Voltage Common Collector (VCC) is a term used in electrical engineering to refer to the positive supply voltage in circuits using Bipolar Junction Transistors (BJTs). It is commonly believed that the term VCC is used to distinguish it from the collector voltage (VC). VCC is the power input of a device and can be positive or negative with respect to the ground (GND). In digital circuits, the VCC rail powers logic elements such as gates, flip-flops, and timing modules. For Transistor-Transistor Logic (TTL) and other bipolar logic families, VCC is traditionally set at +5V.
| Characteristics | Values |
|---|---|
| Full Form | Voltage Common Collector |
| Function | Power input of a device |
| Voltage | Positive or negative with respect to GND |
| Usage | Circuits using Bipolar Junction Transistors (BJT) |
| Other Labels | V+, V- |
| VCC vs VDD | Distinction is semantic; what matters is the voltage level indicated in the electrical characteristics table |
Explore related products
What You'll Learn
VCC is the positive supply voltage for circuits using Bipolar Junction Transistors (BJT)
BJTs are a type of transistor that uses both electrons and electron holes as charge carriers. They are composed of two p-n junctions between two semiconductor types: n-type and p-type. These junctions can be created through various methods, such as changing the doping of the semiconductor material or depositing metal pellets. BJTs have three main terminals: the emitter, base, and collector. The emitter region is typically heavily doped, while the collector is more lightly doped compared to the base.
The BJT's unique structure allows a small current injected at one terminal to control a much larger current between the other two terminals, making it suitable for amplification or switching applications. The efficiency of a BJT is measured by the proportion of carriers that can cross the base and reach the collector. A thin and lightly doped base region helps maximize efficiency by minimizing the recombination of charge carriers.
In circuit diagrams, the direction of current is conventionally shown as the direction in which a positive charge would move. However, in bipolar transistors, currents can be composed of both positively and negatively charged particles. Therefore, arrows on bipolar transistor symbols indicate the p-n junction between the base and emitter and point in the direction of conventional current flow.
