Electric cables are used for transmitting electrical energy and come in a variety of types, sizes, and installation methods. One of the most fundamental ratings assigned to an electric cable is its voltage rating, which is the reference voltage that defines the electrical tests the cable is designed for. Cables are categorized as low voltage (up to 750-1000 V) or medium voltage (1 kV to 36 kV) and are used in a range of applications, from domestic wiring to industrial power installations. Power, data, and control cables must comply with international standards to ensure safety and reliability, encompassing factors such as electrical conductivity, mechanical strength, and resistance to environmental factors. Cable manufacturing and usage standards vary by region, with organizations such as the International Electromechanical Commission (IEC) and British Standard (BS) providing guidelines. Installation processes for medium-voltage power cables can be complex, requiring specialized equipment and skilled personnel to ensure safe and effective energy transmission.
| Characteristics | Values |
|---|---|
| Cable type | Power, data, control, instrumentation, low voltage, medium voltage, high voltage, etc. |
| Cable standards | DIN, NBN, NF, SS, VDE, IEC, EN, SEMKO, SAA, OVE, CEBEC, SEV, NEMA, NEC, UL |
| Cable markings | Temperature ratings or codes, voltage ratings, manufacturer's name, National Test Agency symbol |
| Cable materials | Copper, aluminium, thermoplastic, thermoset, PVC, rubber, XLPE, HEPR |
| Cable applications | Indoor, outdoor, industrial, commercial, residential, special installations |
| Cable destinations | North America, Europe, Asia, South America, Germany, Austria, Belgium, Switzerland, etc. |
Explore related products
What You'll Learn
Cable voltage and temperature ratings
One of the most fundamental ratings assigned to an electric cable is its voltage rating. The rated voltage of a cable is the reference voltage for which the cable is designed and which defines the electrical tests. The rated voltage of a cable is normally expressed by the combination of two values, Uo/U, expressed in volts. Uo is the Root Mean Squared (r.m.s) value between any insulated conductor and ‘earth’ (the metal covering on the cable or the surrounding medium). U is the r.m.s value between any two-phase conductors of a multicore cable or of a system of single-core cables.
There is a third designated term, Um, which is used in some cable standards, defined as the ‘highest system voltage’ for which the cable and its accessories are designed. In an alternating current system, the rated voltage of a cable should be at least equal to the nominal voltage of the system for which it is intended. Different countries and regions have different amperage and voltage requirements, and these factors will affect the size and type of cable needed to supply safe electrical power. For example, in North America, circuit voltage is usually 120V or 240V, using 15A for non-industrial needs. For industrial needs, typical requirements would be 120V, 120/208V or 120/240V using 20A or less. In the European market, non-industrial needs are usually 230V using 16A or less, whereas industrial needs could be 230 or 400V using 32A or less.
The temperature rating of the cable is the rating marked on the cable or implied by the conductor type in the cable. This indicates the minimum temperature rating, and the cable is suitable for use at higher temperatures if marked on the cable or cord. The higher temperatures (above 60°C) only apply to dry applications. Cable for indoor applications is typically rated for at least 60°C, as typical indoor room temperatures range from 20°C to 30°C, and properly operating equipment may generate an additional 30°C. If the product is a heating appliance, a rubber jacketed cable or a special heater type cable is recommended. Outdoor and industrial ambient temperatures and equipment usually have higher extremes, and the cable may need to be rated from -50°C up to 105°C.
All Thermoplastic and Thermoset materials used to make cables will slowly age and deteriorate over time; the rate of deterioration will accelerate as the temperature increases (Arrhenius Law). Therefore, it is common to state a temperature at which the material will continue to operate normally and give an acceptable life; for electric cables, this is known as the “continuous conductor operating temperature” rating.
