The electrical stop light switch in an air brake system is turned on by the activation of the brake pedal. When the brake pedal is pressed, it engages a mechanism that triggers the electrical stop light switch, which is typically located near the brake pedal or within the brake system itself. In an air brake system, the application of the brakes is initiated by the driver pressing the brake pedal, which causes a decrease in air pressure in the brake lines leading to the wheel brakes. This reduction in air pressure activates the brake chambers at each wheel, applying the brakes. The electrical stop light switch is a pressure-sensing switch connected to the brake system's air reservoir. When the driver applies the brakes and the air pressure drops, the pressure change is detected by the stop light switch, which then closes an electrical circuit, causing the stop lights to illuminate.
Explore related products
What You'll Learn
The brake pedal is pressed
The brake light switch is generally located near or above the brake pedal. When the driver presses the brake pedal, the brake lights are turned on. This is an important safety feature, as it provides a visual indication to other road users that the vehicle is slowing down or stopping.
In an air brake system, pressing the brake pedal causes a decrease in air pressure in the brake lines leading to the wheel brakes. This reduction in air pressure activates the brake chambers at each wheel, which then apply the brakes. The electrical stop light switch is typically a pressure-sensing switch connected to the brake system's air reservoir. When the driver applies the brakes and the air pressure in the system drops, the stop light switch detects this pressure change. Once the pressure falls below a certain threshold, the switch closes an electrical circuit, causing the stop lights to illuminate.
In some cars, the brake light switch contains a pair of switches inside, and both will need to be tested if the brake lights are not functioning properly. The switch can be tested with a multimeter without removing it from the vehicle. This involves testing the voltage at the brake light switch connector when the brake pedal is depressed and released. If there is no voltage at the brake switch, the fuse might be blown.
In other cars, the service manual recommends testing the switch continuity with the pedal depressed and released. The correct procedure can be found in the service manual for the specific car. The brake light switch is a critical component, and a car with a faulty brake light switch is unsafe to drive.
