The electrical axis of the heart is a crucial component of electrocardiogram (ECG) interpretation, providing valuable insights into the underlying health of the heart and helping to guide diagnoses. Changes in body position, such as transitioning from sitting to standing, can cause variations in the electrical axis, QRS amplitude, ST segment, and T wave. These shifts are attributed to alterations in the anatomical orientation of the heart within the chest cavity, changes in lung volume, and variations in electrode-skin contact. During exercise, the heart rate increases linearly with the intensity of the physical activity, and this relationship between heart rate and workload can be plotted to observe the heart's chronotropic response. While a rapid heart rate increase during or after exercise may suggest the development of tachyarrhythmia, a sudden decrease in heart rate along with low blood pressure may indicate presyncope or syncope associated with a vasovagal response. Furthermore, abnormal heart rate responses during recovery are strong predictors of all-cause mortality in clinical populations. Therefore, understanding the behaviour of the mean electrical axis during exercise is essential for interpreting ECG readings, making accurate diagnoses, and providing effective patient care.
| Characteristics | Values |
|---|---|
| Normal range of mean electrical axis | Between 0 to +160 degrees in cats and +40 to +100 degrees in dogs |
| Normal range of QRS axis | Between -30° and +90° |
| Abnormal axis deviation | Left Axis Deviation = QRS axis less than -30° |
| Right Axis Deviation = QRS axis greater than +90° | |
| Extreme Axis Deviation = QRS axis between -90° and 180° | |
| Changes in ECG during exercise | Changes in the electrical axis, QRS amplitude, ST segment, and T wave |
| Changes in ECG during rest | Combined lead-I patterns (camel-hump or ST-segment prolongation) |
| Changes in ECG during exercise stress tests | Supine and standing positions |
| Indicators to stop exercise during stress testing | Ventricular fibrillation (VF), sustained ventricular tachycardia (VT), and ST-segment elevation (≥1 mm) in leads without diagnostic Q waves |
| Excessive ST-segment depression (>2 mm of horizontal or downsloping ST-segment depression) or marked axis shift | |
| Arrhythmias other than VT including multifocal PVCs, triplets, supraventricular tachycardia (SVT), heart block, and bradyarrhythmias | |
| Development of bundle branch block | |
| Heart rate response during exercise | Heart rate increases linearly with exercise intensity up to the maximum heart rate |
| Heart rate response post-exercise | A rapid fall in heart rate may precipitate presyncope or syncope associated with a vasovagal response |
Explore related products
What You'll Learn
- Detecting changes in the mean electrical axis requires a multilead ECG
- The hexaxial lead system is divided into four equal quadrants
- A positive QRS in Lead I indicates a normal mean electrical axis
- Right ventricular hypertrophy and right bundle branch block cause a right axis shift
- Changes in body position cause shifts in the electrical axis
Detecting changes in the mean electrical axis requires a multilead ECG
Detecting changes in the mean electrical axis is crucial for understanding the heart's electrical axis and identifying any underlying abnormalities. To achieve this, a multilead ECG is necessary, as it provides a comprehensive view of the heart's electrical activity from different angles.
The electrical axis of the heart is the sum of all depolarization vectors, and determining it is a key step in interpreting an ECG. Myocardial cells are polarized during the resting state, and during depolarization, ion shifts cause an orderly wavefront across the myocardium. This results in the familiar ECG tracing, with the wave of depolarization moving toward or away from the positive lead, creating positive or negative deflections, respectively.
The standard multilead system used in veterinary medicine is the hexaxial lead system, which consists of six limb leads: Leads I, II, and III (bipolar leads) and Leads aVR, aVL, and aVF (unipolar leads). In human electrocardiography, the same leads form the basis of the hexaxial reference system used to calculate the heart's electrical axis in the frontal plane.
To detect changes in the mean electrical axis, a multilead ECG setup is required. A single lead II ECG tracing is usually sufficient for diagnosing arrhythmias, but for identifying changes in the mean electrical axis, additional leads are needed. This helps rule out artifacts as the cause of abnormalities seen in a single-lead tracing and aids in diagnosing conduction abnormalities, detecting ventricular hypertrophy, and determining the origin of arrhythmias.
The process of determining the mean electrical axis involves obtaining a six-lead ECG from a patient positioned in right lateral recumbency, with their limbs perpendicular to their long body axis. One method for estimating the mean electrical axis is to find an isoelectric lead, where the positive and negative deflections of the QRS complex are equal. The lead perpendicular to the isoelectric lead identifies the mean electrical axis. If the QRS complex is predominantly positive in this perpendicular lead, the mean electrical axis is directed toward the positive pole; if it's negative, the axis is directed away from the positive pole.
