The electrical wiring systems in different countries vary, and some countries' electricity circuits do not have an earth wire. For example, in Egypt, the mains electricity has only two wires, live and neutral, without an earth wire. The presence of an earth wire is essential for safety, as it provides a low-impedance path for current to flow back to the incoming neutral in the event of a fault, preventing electrical shocks. However, the absence of an earth wire in some countries' electrical circuits may be due to various factors, such as historical practices, local regulations, or the use of alternative safety measures.
| Characteristics | Values |
|---|---|
| Reason for not using an earth wire | Safety concerns, cost, and incompatibility with other systems |
| Countries without an earth wire | Egypt |
| Alternative methods | Using a nail in a wall, using a residual-current device (RCD), or a ground wire |
| Earthing system implications | Safety, electromagnetic compatibility, and protection against electrical shock |
| Earthing system variations | Single-wire earth return (SWER), protective multiple earthing (PME), and multiple earthed neutral (MEN) |
| Voltage reference | "Ground" is used as a reference point for voltage measurements |
| Grounding terminology | "Equipment grounding conductor", "grounding electrode conductor", "system grounding", and "functional earth" |
| Grounding functions | Protection against electrical shock, surge suppression, EMI filtering, and electrostatic discharge |
| Grounding applications | Rural areas, submarine cables, and measurement instruments |
Explore related products
What You'll Learn
Regulations for earthing systems vary between countries
Regulations for earthing systems vary considerably between different countries. An electrical ground system should have an appropriate current-carrying capability to serve as an adequate zero-voltage reference level. In electronic circuit theory, a "ground" is usually idealized as an infinite source or sink for charge, which can absorb an unlimited amount of current without changing its potential.
In some countries, the ground itself can be used as one conductor of the circuit, saving the cost of installing a separate return conductor. This is known as a single-wire earth return (SWER) AC electrical distribution system, and it is commonly used in rural areas where large earth currents are not likely to cause hazards.
In North America, for example, a unique split-phase system is used to supply most premises with both 240 volts and 120 volts. This allows for the concurrent use of both 240V and 120V circuits, as regulated by local building codes. In North America, the term "equipment grounding conductor" refers to equipment grounds and ground wires on branch circuits.
In Australia and New Zealand, a modified protective multiple earthing (PME) system called multiple earthed neutral (MEN) is used. The neutral is grounded (earthed) at each consumer service point, bringing the neutral potential difference towards zero along the whole length of LV lines.
In the UK and some Commonwealth countries, the term "PNE", meaning phase-neutral-earth, is used to refer to a system where the neutral and earth are bonded together at the point of supply. This is different from the TN-S and TT systems, where the consumer has a low-noise connection to Earth, and any voltages on the N conductor due to return currents and impedance are not an issue.
In some countries, such as Egypt, the mains electricity has only two wires, live and neutral, with no earth wire. This means that there is no protective earth system in place, which can lead to issues with electrical devices and potential safety hazards.
