Proper grounding is essential for an electric fence to work effectively. Ground rods should be placed at least 10 feet apart and should be made from galvanized steel or copper. The length of the ground rod depends on the energizer's joules of output, with higher output requiring more ground rods. The soil type also affects the depth of the ground rod, with sandy or rocky soils requiring additional grounding. To boost pulse strength, you can add a pinhole to the bottom of a bucket and fill it with water to increase the moisture around the ground rod.
| Characteristics | Values |
|---|---|
| Ground rod length | Dependent on the energizer's joules of output. A general rule is to install a minimum of 3 feet of ground rod per joule of output capacity. |
| Ground rod placement | Ground rods should be more than 23m (75 feet) from other grounds, waterlines, or utilities. |
| Ground rod material | Made of either copper or galvanized metal. While copper is more conductive, galvanized rods will last longer. |
| Ground rod clamps | Brass clamps for copper rods, and dissimilar metal (non-corroding) clamps for galvanized rods. |
| Ground rod depth | Should stick out of the soil 10-15 cm (4-6 inches). |
| Soil type | Sandy or rocky soils are less conductive than loamy soils, so systems installed on these types of soils may need to be an earth return type of grounding system. |
| Moisture | The lower and wetter the ground, the better the performance of the ground rods. |
Explore related products
What You'll Learn
The importance of grounding electric fences
Grounding is an essential component of any electric fence. When an animal comes into contact with an electric fence, a pulse travels from the fence, through the animal, and into the soil. The pulse is then captured by the ground system and returned to the energizer. Without proper grounding, the fence's electrical circuit cannot be completed, and it will not be an effective barrier to animals.
The ground system is essential to complete the circuit. When an animal touches the electrically charged fence wire, the animal feels the electric current as the charge passes through its body. The charge then continues the circuit through the earth to the ground rod and up the ground wire to the ground terminal of the charger. If the animal and the ground terminal of the charger are not sufficiently grounded, the path of the electric current cannot be completed, and the animal will not feel the shock. Since the earth provides half of the electric field circuit, it is crucial to have a properly installed ground circuit.
The length of the ground rod depends on the energizer's joules of output. A general rule is to install a minimum of 3 feet of ground rod per joule of output capacity. A 15-joule fence charger will require a minimum of 45 feet of ground rod. These rods must be installed at least 10 feet apart from each other. The lower and wetter the ground they are installed in, the better their performance will be.
Soil type is also an important consideration when grounding an electric fence. Sandy or rocky soils are not as conductive as loamy soils, so systems installed on these types of soils may need to be an earth return type of grounding system. In these cases, it may be necessary to install grounding around the fence to achieve maximum fence efficiency. One solution is to run bare galvanized wire just below the surface of the ground, attached to each post. This provides a direct connection to the fence charger when the animal contacts both the negative and positive strands of the fence at the same time.
