COMSOL Multiphysics® software is a powerful tool for simulating and analyzing various physical phenomena, including electrical circuits. When adding an electrical circuit to a coil in COMSOL, users can utilize the Circuit Extractor add-in to convert electromagnetics simulation results into an Electrical Circuit physics interface. This interface allows for the modeling of currents and voltages in circuits, including voltage and current sources, resistors, capacitors, inductors, and semiconductor devices. The Circuit Extractor also supports automated import and export of circuits as SPICE .cir files, making it convenient for users to modify and customize their circuits. Additionally, COMSOL provides a comprehensive Support Center and discussion forums where users can seek assistance and share insights on specific use cases, such as adding electrical circuits to coils or coupling electromechanics and electrical circuits.
Explore related products
What You'll Learn
Using the Circuit Extractor add-in
The Circuit Extractor add-in is a tool in COMSOL that allows users to extract lumped quantities for electric circuit simulations. It is available for all licenses that offer the AC/DC Module and is automatically installed if the default preferences are set.
The Circuit Extractor add-in offers an easy way to directly convert the results of electromagnetics simulations into an Electrical Circuit physics interface and subsequently into a SPICE file. The supported physics interfaces for performing such an extraction are Magnetic Fields, Currents Only, and Magnetic and Electric Fields for resistances, inductances, or impedances. Multiple physics interfaces and solutions can contribute to the same extracted circuit.
To use the Circuit Extractor add-in, a Stationary Source Sweep or a Frequency Domain Source Sweep must first be solved for the physics of interest. Matrices that are generated when solving such studies are then used for generating the equivalent circuit. After solving, in the user interface of the Circuit Extractor add-in, the user selects the type of Equivalent Circuit and the Evaluation Group corresponding to the desired solution, and presses the Extract Circuit button.
The Circuit Extractor interface offers a few options for modifying the circuit, such as choosing the feeding element type. The user can also decide not to close the conductors in case other circuit elements need to be added manually.
