Roland print heads can be tested by performing a printing test. This involves loading the object to be printed, setting the print area, and pressing the FUNCTION button. If the test print shows fuzzy lines or incomplete colours, it could be due to clogged print heads, incorrect ink types, or sealing issues with the cap tops. In some cases, performing a manual clean or using a different type of cleaning fluid may resolve the issue. Additionally, ensuring regular use and proper maintenance, including checking feed and scan settings, can help prevent print issues. If problems persist, it may be necessary to check the electrical components, such as fuses, transistors, and cables, as electrical issues could be causing the print head to malfunction.
| Characteristics | Values |
|---|---|
| Test print issues | Fuzzy lines, incomplete prints, deflection, banding, clogged heads |
| Causes | Mineral deposits, Infrequent use, incorrect ink type, faulty cap tops, improper cleaning |
| Troubleshooting steps | Wipe print head with a soaked sponge, change wipers frequently, print something every few days, check ink type and cap tops, perform manual cleaning |
| Electrical issues | Blown fuses, fried print head, faulty cables, transistor issues, short circuits |
| Resolution | Replace fuses, check cables, inspect transistors for burn marks, consider replacing the print head |
Explore related products
What You'll Learn
Check for blown fuses
Checking for blown fuses is an important step in electrically testing your Roland print head. A blown fuse can cause one or two print heads to stop working, so it's crucial to identify and replace any blown fuses to restore the printer's functionality. Here's a step-by-step guide to checking for blown fuses:
Identify the Fuses:
Roland printers typically have a few critical fuses that you should be concerned with. The first is the head fuse, which is located on the main board. This fuse is associated with the print head and can cause issues with specific colours if blown. Additionally, there may be fuses on the PCB board, such as one by the power supply regulating AC in, and possibly more, depending on the printer model.
Check the Fuses:
You can use a simple multimeter to test whether a fuse is blown. A multimeter is a device that measures electrical properties, and you can use it to check for continuity in the fuse. If the fuse has continuity, it is intact. If there is no continuity, the fuse is blown and needs to be replaced.
Common Causes of Blown Fuses:
Understanding why fuses blow can help you prevent future issues. Fuses often blow due to power supply fluctuations, electrical shorts, or incorrect handling of cables. For example, disconnecting a cable while the machine is live or fiddling with components while the printer is turned on can lead to blown fuses.
Replace the Blown Fuse:
If you identify a blown fuse, you'll need to replace it. You can purchase replacement fuses from Roland spares or authorised dealers. It is recommended to have some soldering skills or seek someone with such expertise to perform the replacement. The process involves soldering the new fuse onto the main board or PCB board, depending on the fuse's location.
Remember to exercise caution when working with electrical components, and always ensure the printer is unplugged and powered off before attempting any repairs or inspections.
