Running electrical wires through walls can be a challenging task for DIYers, but it is not impossible. The process involves fishing wires through finished walls, which requires some specialty tools and proper techniques. The approach will depend on the scope of the work and whether it involves simply extending a circuit or installing entirely new wiring. It is important to consult local code requirements and to ensure that the wire gauge is appropriate for the amperage of the circuit. Safety precautions, such as wearing gloves when handling certain tools, are also crucial. Running wires through walls may require cutting chases (deep grooves) and using capping or conduit to protect the cables.
| Characteristics | Values |
|---|---|
| Tools | Wire-fishing tools, wire-pulling magnets, angle drills, chisels, mallets, mud rings, markers, hacksaws, chasing machines, etc. |
| Techniques | Mapping out the route, using a stud finder, drilling holes, using hooks and magnets, cutting notches, mounting cables, using plastic trunking, filling channels with plaster, etc. |
| Safety | Consult local code and National Electrical Code requirements, use appropriate wire gauge, follow wiring regulations, ensure cables are adequately protected and enclosed, etc. |
| Scope | Extending a circuit, replacing wiring, adding new switches/lights/outlets, running an entirely new circuit, etc. |
Explore related products
What You'll Learn
Know the scope of the job and the techniques required
The scope of the job and the techniques required will depend on the circumstances and extent of the work. Are you simply extending a circuit from an existing outlet to a new location? Are you running an entirely new circuit from the main service panel to multiple locations? Or are you replacing an entire house full of knob-and-tube wiring with new cable?
If you are adding a new electrical outlet or light fitting, it will almost certainly involve running cable from a power source. If you are adding or extending an electrical circuit, the wire connections are rather easy if you have a basic understanding of electrical work. Fishing the wires through finished walls is the challenging part.
If you are fishing electrical cable through existing walls, you will require specialty tools, but it is possible for DIYers to do the job if they learn the proper techniques. Basic skills for DIY electrical work include knowing how to make connections inside switch, light, and outlet boxes. Being able to "fish" wire through walls opens up even more possibilities, allowing you to add new switches, lights, outlets, or communication cables like Cat 6 exactly where you need them.
Before starting any electrical work, it is important to consult your local code on requirements for running cable. For example, in exposed locations such as open basements or attics, cable usually needs to be run through holes or notches cut in joists rather than stapled to the face of the joists. Additionally, ensure that the wire gauge is appropriate for the amperage of the circuit. Standard 120-volt branch circuits use 12-gauge wire for 20-amp circuits and 14-gauge wire for 15-amp circuits. There may also be arc-fault code requirements to consider when extending a circuit.
When fishing wire through walls, you will need to decide whether to mount cables on the surface of your wall with clips or run them through plastic trunking that can be nailed or screwed to the wall. If you choose to bury the cable in the wall, you will need to create a "chase" or channel in the plaster and run the cable through an oval plastic conduit or "top-hat" capping for longer lengths. Always run cable vertically to a fitting in a solid wall so that you will know its approximate position when the work is finished. Plan the route of the channel using a spirit level or plumb line and mark it in pencil.
Cutting chases in walls requires following definite guidelines to ensure the safe installation of electrical cables. In a cavity wall, vertical chases should not be deeper than one-third of the thickness of the skin they are being placed in. Additionally, all electrical cables should be set into walls at a minimum depth of 50mm if they are not mechanically protected. If cables are installed at depths of less than 50mm, they must be RCD protected or enclosed in steel or plastic tubing.
There are various tools that can assist in fishing wire through walls, such as small hooks made from cable or coat hangers, magnets, and fibreglass sticks equipped with hooks, loops, or magnets. When drilling holes, use a spade bit in an angle drill or an angle attachment. It is also important to map out the route for your wire and scan the wall with a stud finder to locate any blocking that might obstruct the path.
Finding Electrical Wiring: Wall Scanning Techniques
You may want to see also
Explore related products
Understand the tools needed to fish wires through walls
Fishing wires through walls can be a challenging task, but with the right tools, it can be made easier. The tools you will need depend on the circumstances and the extent of the work. Here is a list of tools that will help you fish wires through walls:
Fish Tape
Fish tape, also known as a fish stick, is a long, flexible steel or fibreglass rod used to guide wires through walls. It is stiff enough to be pushed through cavities and holes in the wall but flexible enough to bend around corners. Fish tapes typically have a hook or a loop at the end to attach wires. They come in various materials, including steel, fibreglass, and polyester, depending on whether you are working with energised panels or conductors.
Wire-pulling Magnets
Magnets can be used to pull wires through insulated stud bays. The Magnepull, for example, consists of a steel leader and a roller magnet. It can also be used to retrieve lost tools from inside walls. Wire-pulling magnets can be purchased from electrical supply stores and range in price from $40 to $125.
Drills and Bits
A drill is necessary for creating holes in walls, floors, and ceilings to feed wires through. When drilling between stud bays, a dedicated angle drill or a cheaper alternative can be used. A spade bit can also be used to cut through studs to run wires horizontally if you don't have access to the basement or attic.
Hooks
Small hooks made from cable or coat hangers can be useful for grabbing cables just out of reach. They are simple, economical tools that can be made at home.
Mud Rings
Mud rings, or single-gang boxes, are used to prevent marring drywall when pulling cables. They also have markers that outline the perfect hole size and shape for the cables to pass through.
Other Tools
Other tools that may be useful include a stud finder to locate blocking in your desired route, a chisel and mallet for cutting notches in exposed nogging, and various mounting tools such as nails, screws, and clips to secure cables to the wall.
Disassembling Electric Hospital Beds: A Step-by-Step Guide
You may want to see also
Explore related products
Learn how to cut and fill chases in walls
Burying electrical cables in walls is a common practice to avoid untidy wiring. This process involves cutting and filling chases in walls. Here is a step-by-step guide on how to do it:
Planning:
Before starting any work, it is crucial to plan the layout. Identify the route the wires will take and mark the wall accordingly. Use a pipe and cable detector to ensure there are no pipes or cables in the way. Also, be mindful of local codes and requirements for running cables.
Cutting the Chase:
Use a chasing machine or a handheld cutting tool with a double diamond blade to cut the chase. The depth of the cut should be slightly more than the depth of the conduit to allow for filling. If using a handheld cutting tool, cut two slots of specific depth and width, and knock out the waste between the cuts with a cold chisel. Ensure the depth is set correctly, as cutting chases is a dusty job and you want to minimise the mess. Cover any furniture or objects that cannot be moved with dust sheets.
Running the Cable:
Once the chase is cut, run your desired cable through it. Measure and cut your trunking/PVC capping to length, and secure it over the cable with screws, wall plugs, or concrete nails. If your trunking/conduit has capping, remove it, fix the conduit, run the cables, and then replace the cap.
Filling the Chase:
Filling the chase is a matter of personal preference and the finish you desire. You can use patching plaster, filler, or bonding plaster to fill the chase. Fill the chase from the back and around the conduit/pipe from the front. Use a small trowel to push the filler into the corners and sides of the wall. If using plaster, wet the chase with clean water before applying it to aid adhesion. If the wall will be painted or papered, cut back the surface of the filler by about 3mm before it fully hardens.
Cleaning Up:
Once everything is in place, clean up any dust or mess. Use a vacuum to ensure all dust is removed, as it can be abrasive and damage delicate surfaces.
By following these steps, you can successfully cut and fill chases in walls to run electrical cables neatly and safely.
Childproofing Electric Baseboard Heaters: A Safety Guide
You may want to see also
Explore related products
Understand the requirements for running cables
Running electrical cables through walls is a challenging task that requires careful planning and execution to ensure safety and compliance with local regulations. Here are some key requirements to understand before starting this project:
Understand the Scope of Work
The approach to running cables will depend on the scope of the project. Are you extending a circuit from an existing outlet to a new location, installing a new circuit from the main service panel to multiple locations, or replacing old wiring with new cables? The scope of the work will determine the best methods and techniques to employ.
Consult Local Codes and Regulations
It is crucial to consult your local codes and regulations for running electrical cables. These regulations may vary depending on your location, so be sure to refer to the specific requirements in your area. For example, in exposed locations like open basements or attics, the type of cable used and its installation method may be specified, such as running NM cable through holes or notches in joists rather than stapling it to the face of the joists.
Select Appropriate Cable Type and Gauge
Choosing the right type of cable is essential. For instance, modern PVC cable should be kept away from polystyrene insulation to prevent damage to the cable insulation. Additionally, ensure that the wire gauge matches the amperage of the circuit. Standard 120-volt branch circuits typically use 12-gauge wire for 20-amp circuits and 14-gauge wire for 15-amp circuits.
Comply with Depth and Protection Requirements
There are specific requirements for the depth at which cables should be installed. In general, cables should be set into walls at a minimum depth of 50mm if they are not mechanically protected. If the installation depth is less than 50mm, additional protection is required, such as RCD protection or enclosing the cables in steel or plastic tubing/capping.
Use Proper Tools and Techniques
Running cables through walls requires specialty tools and techniques. Familiarize yourself with the necessary tools, such as wire-fishing tools, magnets, hooks, and drilling equipment. Understand how to safely drill holes, cut notches, and feed cables through walls while complying with safety regulations.
Plan the Cable Route
Before beginning any work, carefully plan the route your cable will take. Use a stud finder to map out the path and identify any potential obstructions. Consider the location of inlet/outlet pieces and accessories, and ensure your cable routing complies with prescribed zones, such as expected horizontal and vertical paths and bands in room corners or at wall-to-ceiling junctions.
By understanding and adhering to these requirements, you can ensure a safe and compliant cable installation project. Remember, electrical work can be dangerous, so always prioritize safety and consult with a certified electrician if you have any doubts or concerns.
Learn the Electric Slide in Five Easy Steps
You may want to see also
Explore related products
Know how to connect wires inside switch, light, and outlet boxes
Knowing how to connect wires inside switch, light, and outlet boxes is a basic skill of DIY electrical work. It is important to be able to "fish" wire through walls to add new switches, lights, outlets, or communication cables. Before starting any electrical work, it is important to ensure the circuit is turned off and test wires and connections with a voltage tester to make absolutely sure they are de-energized.
For a light switch, turn it on and flip the breakers until the light goes off. Before digging into a switch or receptacle outlet, test the wires and connections. Carefully remove cover plates and devices, and do not grab switches or receptacles by the terminal screws.
When wiring a switch box, it is important to keep your work neat and organized. One convention is to run the cable feeding power into the box through a bottom knockout and cables going to lights or receptacles down the line through knockouts in the top. Carefully fold the wires into the box without tangling them and push them to the back of the box so they are not damaged during drywalling. When installing the switches, pull out the black and ground wires and connect them to their respective switch terminals.
Loose wires can arc and overheat, creating a potential fire hazard. If you notice loose outlets, fix them by shimming under the screws with spacers to create a tight connection to the box. Electricians call these plastic spacers "caterpillars," but you can also use a small nut or spiral of copper wire.
DIY Electric Fence Tester: Building a Simple Device
You may want to see also
Frequently asked questions
You can put electric cable in a wall by cutting a hole in the wall and using wire-fishing tools to feed the cable through the hole.
You will need a tool to cut a hole in the wall, such as a chisel and mallet, a spade bit and angle drill, or a chasing machine. You will also need wire-fishing tools, such as a self-made small hook, magnets, or a fibreglass stick.
The best way to run cable through a finished wall depends on the circumstances and the scope of the job. If possible, it is best to run the cable through an attic, crawl space, or basement, and then into the stud cavity.
For unfinished walls, you can simply mount cables on the surface of your wall with clips or run them through plastic trunking.
Putting electric cable in a wall can be dangerous, and it may be prohibited unless you are a "competent person". Before starting, consult your local code on requirements for running cable, and ensure your work will be compliant with electrical regulations. Cables should be set at a minimum depth of 50mm or protected by capping or conduit.
