Engineering drawings, also known as technical drawings, are detailed outlines that provide the information and requirements needed to manufacture an item or product. They are like a graphical language that communicates ideas and information. To read engineering drawings, one must understand the basics, such as lines, dimensions, scales, symbols, and notations. It is important to be able to identify the different types of drawings, such as blueprints, diagrams, and schematics, and to recognize standard symbols and abbreviations that represent materials, geometric characteristics, surface finishes, and electrical components. Reading mechanical drawings involves understanding tolerances and projection lines, while electrical drawings may focus on connections, components, and electrical relationships within a circuit. By interpreting engineering drawings accurately, one can gain valuable insights, make informed decisions, and communicate more effectively on projects.
| Characteristics | Values |
|---|---|
| Purpose | Mechanical and electrical drawings provide detailed outlines that represent the critical information and requirements needed to build or manufacture a specific item or product. |
| Nature of Information | These drawings communicate design information, specifications, and instructions. They include details such as dimensions, tolerances, finishes, materials, and assembly instructions. |
| Symbols and Abbreviations | Drawings use symbols and abbreviations to convey specific information. Common symbols may represent materials, geometric characteristics, surface finishes, fasteners, electrical components, and other standard elements. |
| Standardization | In the US, symbols and abbreviations are standardized by the American National Standards Institute (ASMI) and the American Society of Mechanical Engineers (ASME). |
| Reading Approach | To interpret a drawing, consider the context, scale, and projection lines. Refer to the legend or key to understand the symbols used. Pay attention to annotations, notes, and accompanying tables or charts, as they provide additional information or context. |
| Title Block | The title block contains basic information about the drawing, including the company and engineer's details, the name and identifying information of the object, and the units of measurement used. |
| Revision Block | The revision block details changes made to the original design, including the dates, descriptions, and approving authorities. |
| Center Lines | Center lines indicate the exact geometric center of the assembly and are made of lighter long and short dashes. |
Explore related products
What You'll Learn
Recognise standard symbols
Recognising standard symbols is a key part of understanding mechanical and electrical drawings. Symbols are used to represent various mechanical, electrical, and physical attributes of components, assemblies, and systems. They are essential for clearly conveying the specifications of these elements.
To start, it's important to understand the key or legend that defines each symbol. This will help you interpret the drawings accurately. Familiarise yourself with standard symbols such as lines (solid or dashed), shapes (like circles, squares, triangles, and hexagons), and notations (diameters, angles, and tolerances). For instance, a circle often represents a hole or drilled feature, while a square indicates a machining operation or process.
In mechanical engineering drawings, symbols are used to represent components such as fasteners, shafts, bolts, nuts, screws, and washers. These symbols guide CNC machining operations to ensure each component is fabricated to the correct specifications.
Electrical symbols, on the other hand, are often pictograms that represent electrical and electronic devices or functions, such as wires, batteries, resistors, capacitors, transformers, and transistors. These symbols are largely standardised internationally but may vary based on country, engineering discipline, or traditional conventions. For example, the ground symbol, represented by GND, indicates an electrical ground connection.
It's important to note that the specific symbols used can vary depending on industry, standards, and specific applications. Always refer to the relevant standards or guidelines specific to your field for a comprehensive list of symbols and their meanings.
