Resistors are passive devices that are essential in modern-day electronics, regulating current flow and controlling voltage. Before the 1920s, there was no standard colour code for resistors, but today, the EIA colour code is used to indicate the values or ratings of electronic components. There are several methods to remember the resistor colour codes, including creating your own mnemonic or memorising the colours of the rainbow.
| Characteristics | Values |
|---|---|
| Number of bands | Between 3 and 6, with 4 being the most common |
| First few bands | Represent digits in the value of resistance |
| Multiplier band | Signifies moving the decimal right or left |
| Last bands | Represent tolerance and the temperature coefficient |
| Tolerance bands | Gold, Silver, None for 5%, 10%, 20% |
| Mnemonic | Bright Boys Rave Over Young Girls But Veto Getting Wed. Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Grey, White <=> 0, 1, 2, 3, 4, 5, 6, 7, 8, 9 |
Explore related products
What You'll Learn
The colours represent the first and second digits of the value
The colours of electrical resistor colour codes represent the first and second digits of the value. The colours are black, brown, red, orange, yellow, green, blue, violet, grey, and white, which represent 0, 1, 2, 3, 4, 5, 6, 7, 8, and 9, respectively. Gold and silver are also sometimes used to represent 5% and 10% tolerance, respectively.
There are several resistor colour code mnemonics to help remember the colours and their respective values. One of the most well-known mnemonics is "Bad Boys Rape Our Young Girls But Violet Gives Willingly", where the first letter of each word corresponds to the colours black, brown, red, orange, yellow, green, blue, violet, grey, and white. However, this mnemonic has been criticised for its offensive and inappropriate nature, and some people prefer to use alternative phrases that do not contain violent or sexist language.
Some alternative mnemonics include "Bright Boys Rave Over Young Girls But Veto Getting Wed", "Better Be Right Or Your Great Big Venture Goes West", and "Big Beautiful Roses Occupy Your Garden But Violets Grow Wild". Another approach is to simply memorise the colours and their values without using a mnemonic, which can be done by creating flashcards, using a cheat sheet, or through repeated exposure and practice.
It is important to note that resistor colour codes are read from left to right, and the first two colours represent the first and second digits of the resistance value, while the third colour represents the decimal multiplier. For example, a resistor with the colours brown, green, and silver would be a 15-ohm resistor, while silver, green, and brown would represent 950 ohms. Additionally, it is assumed that you read the colours from the outside towards the inside of the resistor.
