Installing an electric fan mounting bracket is a relatively straightforward process, but it's important to ensure that the correct tools and safety measures are in place before beginning. The first step is to ensure that the power to the fan is shut off. Next, you'll need to select the correct mounting bracket for your fan. Some fans come with their own brackets, but if not, you can purchase a universal bracket or fabricate your own. Once you have the bracket, you'll need to align it with the fan housing and drill holes to attach it securely. Finally, you can connect the bracket to the fan, ensuring that the fan spins freely and that there are no obstructions.
| Characteristics | Values |
|---|---|
| Number of brackets required | 4 |
| Ease of installation | Easy |
| Quality | Good |
| Fit | Good |
| Use | Can be used in addition to the brackets that come with the kit |
| Where to buy | SPAL website or Amazon |
| Additional items required | Fan gasket |
| Fan blade types | 4-blade, 5-blade, 6-blade |
| Fan size | 12" |
| Mounting location | Brackets attach directly to the fan shroud |
| Mounting hardware | Bolts, screws, nyloc nuts, nylon insert locking flange nuts, flange bolts |
