There are many reasons why you might want to split an existing electrical circuit, such as having too many outlets connected to one circuit breaker. Before starting any electrical work, it is important to ensure that you have turned off the power to the circuit you are working on. If you cannot find the correct circuit breaker, you will need to turn off the main breaker. One way to split a circuit is to run a new cable directly from the panel to a junction box and split it there. However, it is important to spend time analyzing the existing circuit and understanding how it is run before deciding where to split it.
Characteristics and Values for Splitting an Electrical Circuit
| Characteristics | Values |
|---|---|
| Circuit analysis | Spend time analyzing the existing circuit to understand how it is run and where to split it. |
| Circuit type | Choose between a 15-amp or 20-amp circuit, considering the number of receptacles and your specific needs. |
| Sub-panel | Determine if a sub-panel is required or if the existing one is sufficient. |
| Safety | Ensure the power is turned off at the electrical box before starting any work. |
| Wiring method | Select an appropriate wiring method, such as pigtailing or direct wiring, considering the advantages and disadvantages of each. |
| Cable type | Use a 12-gauge wire for 20-amp breakers and a 14-gauge wire for 15-amp breakers, matching the wire size with the existing setup. |
| Fault testing | Perform fault testing and address any issues on a time and materials basis. |
| Circuit protection | Install Arc Fault Circuit Interrupters (AFCIs) to protect against overload and common sources of overload, such as window air conditioners or hair dryers. |
| Cost | Consider the cost of hiring an electrician or performing the work yourself. The price for a sub-panel and installation can vary. |
Explore related products
What You'll Learn
Understand the risks and safety measures
Working with electricity is inherently risky, and it is important to take precautions to ensure your safety. Before beginning any work, locate and turn off the power to the electrical receptacle you are replacing at your electrical box. If you cannot find the correct circuit breaker, you will need to turn off the main breaker, cutting off power to your entire house.
If you are unfamiliar with electrical work, it is best to hire a professional electrician. They will be able to advise on the best course of action and ensure that any work is carried out safely and correctly. If you choose to proceed with the work yourself, ensure you have a basic understanding of how electrical receptacles work and take the necessary precautions, including using a non-contact voltage tester to ensure the power is off.
One of the risks of direct wiring through a receptacle is that if the original outlet loses power or develops an issue, all the receptacles downstream will be affected and lose power. Additionally, loose wires on a direct-wired receptacle can pose a fire hazard as the entire circuit's current flows through a single path. Pigtail wiring can mitigate this risk as it allows for the removal of a receptacle in the middle of the circuit without affecting the others.
When adding a new electrical outlet, it is important to calculate the number of receptacles your circuit can support to avoid overloading the circuit and tripping the breaker. This can be done by dividing 80% of your circuit breaker's amp rating by 1.5, the amperage required for each outlet.
