The mean electrical axis is a term used in veterinary medicine to describe the standard multilead system used to detect changes in the electrical axis of the heart. Leads I, II, and III are bipolar leads, meaning they have a positive and negative pole, whereas leads aVR, aVL, and aVF are unipolar leads, meaning they only have a positive pole. The positive pole of lead aVF is at the left foot, and the direction from the negative end to the positive end is called the axis of the lead. The mean electrical axis can be estimated by examining the relative size of the QRS complexes in leads I and aVF.
| Characteristics | Values |
|---|---|
| Full Form | Augmented Voltage Foot |
| Lead Placement | Left Foot |
| Normal Direction | +90° |
| Axis Determination | Positive pole of lead vectors |
| Axis Determination (Hexaxial System) | +160° (Cats) |
| Axis Determination (Quadrant Method) | Positive in Lead I and aVF: 0° to +90° (Normal Axis); Positive in Lead I and Negative in aVF: 0° to -90° (LAD); Negative in Lead I and Positive in aVF: +90° to 180° (RAD); Negative in both Lead I and aVF: -90° to 180° (Extreme Axis) |
| Axis Determination (Isoelectric Lead Method) | Locate the most isoelectric limb lead and determine the axis as 90° from the positive pole of that lead |
Explore related products
What You'll Learn
- AVF stands for augmented vector foot
- The electrical axis is determined by examining the QRS complexes in specific leads
- The positive ends of leads I, II, and AVF are 0°, +60°, and +90° respectively
- The mean electrical axis is approximated by determining the quadrant it lies within
- The QRS axis must be ±90° from lead AVL, either at +60° or -120°
AVF stands for augmented vector foot
In the context of electrical axis, AVF stands for augmented vector foot. It is a unipolar lead with a single positive electrode at the left foot, capturing the electrical activity moving towards the inferior part of the heart. The positive end of lead aVF is +90°.
The mean electrical axis can be estimated by examining the relative size of the QRS complexes in leads I and aVF. The mean electrical axis will be closer to the larger of the two. The quadrant graphing method involves dividing the hexaxial lead system into four equal quadrants by leads I and aVF. Arrows are drawn on leads I and aVF in the direction of the predominant QRS complex deflection. For example, if lead I is predominantly negative, an arrow will be drawn towards the negative pole of lead I. If lead aVF is also predominantly negative, an arrow will be drawn away from its positive pole. This would place the mean electrical axis in the upper right quadrant, indicating a right axis shift.
The QRS axis must be ±90° from lead aVL, either at +60° or -120°. With leads I (0), II (+60), and aVF (+90) all being positive, the axis must lie somewhere between 0 and +90°. This puts the QRS axis at +60° – a normal axis. The addition of lead II can help determine pathological left axis deviation (LAD) from a normal axis/physiological LAD.
The most efficient way to estimate the axis is to look at lead I and lead aVF. To do this, examine the QRS complex in each lead and determine if it is positive, isoelectric (equiphasic), or negative. A positive QRS in lead I puts the axis in roughly the same direction as lead I. A positive QRS in lead aVF similarly aligns the axis with lead aVF. Combining both coloured areas, the quadrant of overlap determines the axis. So, if lead I and aVF are both positive, the axis is between 0° and +90° (a normal axis).
