In electrical wiring, L and N are used to represent live and neutral wires, respectively. The L wire is also referred to as the line or phase wire, while the N wire is sometimes called the earth or mean earth wire. These terms are used to differentiate the wires' functions and connections within an electrical system. The colours of the wires differ depending on the country, for example, in Germany, the default colours for a 3-wire cable are green/yellow for the earth, brown for live, and blue for neutral. It is important to correctly identify and handle these wires during electrical work to ensure safety and avoid accidents.
Explore related products
What You'll Learn
L and N stand for Live and Neutral respectively
L and N stand for Live and Neutral, respectively. In an AC power supply, the L wire is the Live wire, which carries the current. It is also called the Line or the Hot Line. The voltage of the Live wire is 120V AC relative to the Neutral wire.
The N wire is the Neutral wire, which is connected to the ground and has 0V compared to the ground. It is also referred to as Earth or the Nothing Line. Neutral is typically clamped to the earth where the cable enters a house or at the local substation. The ground itself is made by pounding an 8-foot rod into the earth, and the neutral is connected to this line through the ground wire in one place, such as the main breaker box.
The Live and Neutral wires are essential for supplying electrical circuits with alternating current. They are not interchangeable for safety reasons. In a 2-core cable, the Live wire is brown or black, and the Neutral wire is blue. In older installations, the Live wire may be black without different wire colours. In a 3-core cable, there is an additional wire: PE (Protective Earth), which is yellow-green.
In Germany, the default colours for a 3-wire cable are green/yellow for Earth, brown for Live, and blue for Neutral.
