A shunt is an electrical device that creates a low-resistance path for an electrical current, allowing it to flow to an alternative point in the circuit. This device is used to divert current away from a system or component to prevent overcurrent and is commonly used in power distribution systems, electrical measurement systems, and automotive and marine applications. Shunts are also used to measure the electric current, both alternating and direct, and are often used in battery systems for monitoring.
Characteristics and Values of Shunt in Electrical Engineering:
| Characteristics | Values |
|---|---|
| General Function | To provide a low-resistance path for an electrical current in a circuit |
| Other Functions | To divert current away from a system or component, to prevent overcurrent, to measure current, to protect equipment |
| Use Cases | Power distribution systems, electrical measurement systems, automotive and marine applications, lightning arresters, battery monitors |
| Placement | On the negative lead near the batteries to record all currents flowing in and out |
| Measurement | Shunts are rated by maximum current and voltage drop at that current |
| Accuracy | Common accuracy specifications: ±0.1%, ±0.25%, ±0.5% |
| Speed | Disconnecting the shunt from the sense line can increase the speed of the controller |
| Testing | High-precision current shunts are used in the bench testing of equipment, often in combination with a voltmeter |
