A relay is an electrically operated switch that is used to protect electrical circuits from faults and overload by controlling the power and switching the circuit on or off. The term relay comes from the French word relais, meaning to pass on. Relays are used in a variety of applications, from industrial uses to home appliances, and can be divided into two main categories: movable contacts (mechanical relay) and no movable contacts (MOS FET relay, solid-state relay). Solid-state relays are known for their quick operation and long life compared to electromechanical relays.
| Characteristics | Values |
|---|---|
| Definition | An electrically operated switch |
| Function | Protect electrical circuits from overload or faults, control a circuit by an independent low-power signal, and control several circuits by one signal |
| Types | Electromechanical relays (EMR), solid-state relays (SSR), Reed relays, overload relays, IDMT relays, differential relays, DPDT relays, MOS FET relays |
| Components | Coil, iron core, armature, contacts |
| Uses | Lighting control systems, protection systems for electronics, computer interfaces, sensitive appliances, command contactors, control motors, telecommunications, car electrical systems, industrial automation systems, home appliances, manufacturing, building automation |
Explore related products
What You'll Learn
Relays are electrically operated switches
A relay is an electrically operated switch that is commonly used in circuits and systems to control higher power signals with lower power inputs. The term "relay" comes from the French word "relais", which means "to pass on". In simple terms, a relay allows a small electrical circuit to switch a separate high-powered circuit.
Relays are used to protect electrical circuits from overload or faults. They were first used in long-distance telegraph circuits as signal repeaters that transmitted a refreshed copy of the incoming signal onto another circuit. Relays were also used extensively in telephone exchanges and early computers to perform logical operations.
The primary function of a relay is to protect the electrical system from too high a voltage or current, allowing the safe operation of any equipment it connects to. They are commonly found in a variety of applications, from commercial and industrial uses to home and consumer products. These include lighting control systems, protection systems for electronics, computer interfaces, sensitive appliances, command contactors, control motors, and telecommunications, among others.
Relays can be divided into two main categories: Movable contacts (mechanical relay) and no movable contacts (MOS FET relay, solid-state relay). A simple electromagnetic relay consists of a coil of wire wrapped around a soft iron core (a solenoid), an iron yoke, a movable iron armature, and one or more sets of contacts. The coil receives an electric signal and converts it into a mechanical action, opening or closing the electric circuit. When an electric current is passed through the coil, it generates a magnetic field that activates the armature, and the consequent movement of the movable contact(s) either makes or breaks a connection with a fixed contact.
