Physical connection in the context of electrical components refers to the electromechanical devices that join electrical conductors to create an electrical circuit. Electrical connectors are used to physically join wires, cables, printed circuit boards, and electronic components to transmit data, power, and signals. These connectors can be divided into four basic categories: inline or cable connectors, chassis or panel connectors, PCB mount connectors, and splice or butt connectors. They are designed to reduce the time, effort, and manpower needed for manufacturing, assembling, and installing electrical devices and wiring. The fundamental purpose of electrical connectors is to ensure that electrical circuits and devices are connected reliably and efficiently.
| Characteristics | Values |
|---|---|
| Purpose | To connect electrical conductors (e.g. wires, cables) to create an electrical circuit |
| Types | Inline/cable, chassis/panel, printed circuit board (PCB) mount, splice/butt, high-voltage, D-shaped, lighting, card edge, USB, RJ45, DEUTSCH, AMP, M8/M12, etc. |
| Design | Circular, rectangular, D-shaped, etc. |
| Gender | Male (plug) and female (socket) components |
| Current Rating | Typically 1A to 50A, but can vary depending on the application |
| Voltage Rating | 50V, 125V, 250V, 600V, etc. |
| Operating Temperature | Depends on the connector and application |
| Contact Pitch | Distance between adjacent pins or terminals, usually measured in mm |
| Materials | Copper, gold, plastic, ceramics, etc. |
| Connection Methods | Screw, crimping, soldering, plug termination, etc. |
| Protection | ESD shielding, backshells, hermetic seals, ingress protection, etc. |
| Applications | Aerospace, automotive, audio/video production, lighting control, low-voltage power supplies, industrial automation, etc. |
