Electrical resonance is a phenomenon that occurs in an electrical circuit at a particular resonant frequency when the impedances or admittances of circuit elements cancel each other out. This happens when the impedance between the input and output of the circuit is low and the transfer function is close to one. Resonant circuits are often built using an inductor, such as a coil, connected in parallel to a capacitor. The response of the circuit to different frequencies depends on the inductance and capacitance of the circuit and peaks at one frequency value, where the current flow resonates most strongly with the input signal.
| Characteristics | Values |
|---|---|
| Definition | An electric circuit which has very low impedance at a certain frequency. |
| Circuit Elements | Resistor, Inductor, and Capacitor. |
| Connection | The elements can be connected in series or in parallel. |
| Impedance | In the resonance condition, the impedance in the circuit is minimum, and the current is maximum. |
| Applications | Tuning, filtering, stabilizing frequency, blocking frequencies, wireless transmission, and motors |
| Q Factor | The quality of resonance is determined by the Q factor, which is a function of resistance, inductance, and capacitance. |
Explore related products
What You'll Learn
Resonant frequency
Electrical resonance occurs in an electric circuit at a particular resonant frequency when the impedances or admittances of circuit elements cancel each other out. In some circuits, this happens when the impedance between the input and output of the circuit is almost zero and the transfer function is close to one.
The resonant frequency of an RLC circuit can be calculated using the equation:
$$\displaystyle \omega = 2\pi f$$
Where $f$ is the resonance frequency in hertz, $L$ is the inductance in henries, and $C$ is the capacitance in farads.
Resonant circuits are commonly used in wireless (radio) transmission and reception, as well as in radio and television tuners to select specific frequencies. They can also be used to prevent the waste of electrical energy by using parallel resonance circuits, which maintain the same resonant current in the circuit and convert all the current into useful work.
