Electric circuit diagrams are simplified graphical representations of electrical circuits. They use lines and symbols to represent the connections and components of a circuit. There are different types of electrical diagrams, including schematic diagrams, pictorial diagrams, and block diagrams. Schematic diagrams focus on functionality and use symbols to represent the arrangements and connections between electrical components. Pictorial diagrams are more simplified and use graphic representations instead of symbols. Block diagrams use blocks to represent the main electrical components for overall systems. These diagrams are used for the design, construction, and maintenance of electrical and electronic equipment.
| Characteristics | Values |
|---|---|
| Wires | Straight lines |
| Power source | Battery |
| Load | Light bulb |
| Switch | Two small circles with a gap between them |
| Electric cell | Two parallel lines, with the longer line representing the positive terminal and the shorter line representing the negative terminal |
| Electric bulb/lamp | A circle with a cross inside |
| Resistor | A zigzag line |
| Variable resistor | Resistor symbol with an arrow or diagonal line passing through it |
| Ammeter | A circle with the letter "A" inside |
| Voltmeter | A circle with the letter "V" inside |
| Wire joint | A dot or a small solid circle |
| Schematic diagrams | Show the flow of an electrical circuit and use schematic symbols to represent arrangements and connections between components |
| Pictorial diagrams | Simplified diagrams that use graphic representations over symbols |
| Block diagrams | Use blocks to represent main electrical components |
Explore related products
What You'll Learn
- Electric circuit diagrams use lines and symbols to represent connections and components
- Schematic diagrams show the flow of an electrical circuit with a focus on functionality
- Pictorial diagrams are simplified, using graphic representations over symbols
- Block diagrams use blocks to represent main electrical components
- Symbols for wires, bulbs, switches, and batteries are used to represent their function in a circuit
Electric circuit diagrams use lines and symbols to represent connections and components
Electric circuit diagrams are simplified graphical representations of electrical circuits. They use lines and symbols to represent connections and components. These diagrams are used for the design, construction, and maintenance of electrical and electronic equipment.
The wires in a circuit are shown using straight lines. A wire joint, where two or more wires intersect or connect, is indicated by a dot or a small solid circle. When two wires cross without a dot or circle, it means they are not electrically connected.
Different components of a circuit are represented by different symbols. For example, an electric cell is represented by two parallel lines, with the longer line indicating the positive terminal and the shorter line indicating the negative terminal. A battery, which consists of multiple electric cells, is represented by two or more of these electric cell symbols arranged in a series.
Other symbols include a circle with an "X" inside to represent an electric bulb or lamp, and a zigzag line to represent a resistor. A switch is represented by a line with a gap or break in it. When the switch is closed or turned on, the gap is bridged, indicating the flow of current.
Schematic diagrams are a type of electric circuit diagram that primarily focuses on functionality and uses schematic symbols to represent the arrangements and connections between electrical components. Pictorial diagrams, on the other hand, are more simplified and use graphic representations over symbols and abbreviations. Block diagrams represent the main electrical components as blocks in an overall system.
