The 700R4 transmission was made between 1982 and 1992 and was a 4-geared hydraulic automatic transmission with the 4th gear as an overdrive gear. In 1993, GM switched to the electronic version of the 700R4/4L60, so some 1993 models had the non-electronic 4L60, while some later 1993 models had the electronic 4L60E. The 700R4 transmission sometimes leaked, which could cause low transmission fluid levels. There were both mechanical and electronic speedometers on the 700R4 transmissions.
| Characteristics | Values |
|---|---|
| Years | 1982–1993 |
| Speedo Cable | Mechanical or electronic |
| Transmission | 4-geared hydraulic automatic transmission with the 4th gear, an overdrive gear (30% increase) |
| Case Length | 23.5″ |
| Weight | 170 lbs without fluid |
| Transmission Case Bolts | 16 |
| Transfer Case | Aluminum |
| Transmission Fluid | Dextron VI, with a capacity of 11 Quarts |
| Torque | 350nm |
Explore related products
What You'll Learn
The 700R4 transmission was made between 1982 and 1992
The 700R4 transmission had both mechanical and electronic speedometers. The earliest 700R4 transmissions used a TV cable as the speedometer. Later models from 1990 to 1993 used an electronic speedometer. Some sources state that 1987 was the year when electronic speedometers were introduced to the 700R4 transmission, while others mention that it was in 1993. It is possible that the electronic speedometers were introduced in select models in 1987 and became more widespread in 1993.
The presence of an electrical plug indicates an electronic speedometer, while a thicker cable coming out from the rear suggests a mechanical speedometer. The electronic speedometer uses a pulse generator and a steel reluctor wheel on the tail shaft, while the mechanical speedometer uses a cable drive. Converting from a mechanical to an electronic speedometer requires replacing the cable drive with an electronic sender and associated parts.
The 700R4 transmission was known for its reliability, but it was not without its issues. Leaks could occur, leading to low transmission fluid levels. Lack of maintenance, such as not changing the transmission fluid regularly, could also cause damage to the transmission. Additionally, the torque converter could fail, requiring replacement. Despite these potential issues, the popularity of the 700R4 transmission ensured that parts were readily available and affordable.
