In-lens detectors are a type of secondary electron detector used in scanning electron microscopes (SEMs) to collect secondary electrons (SEs) and form images. They are located in line with the field emission gun, perpendicular to the surface of the sample. In-lens detectors utilize low acceleration voltage and a decelerating electric field to collect near-axial backscattered electrons (BSEs) with high angular aperture. The design of the in-lens detector allows for the detection of low-energy SEs, providing useful information for profiling membrane nanostructures and improving image resolution in biological samples.
| Characteristics | Values |
|---|---|
| Detector design | Based on the standard in-lens detector used in FEI SEMs |
| Function | Collects BSEs that reach the objective lens but have a high emission angle |
| Contrast and resolution | Affected by the interaction volume and the signal from the surface layer of the sample |
| Signal | The InLens detector is located in line with the field emission gun, perpendicular to the surface of the sample |
| Imaging | Enables imaging with LLE using simple high-pass filtration |
| Efficiency | Depends on the electric field of the electrostatic lens |
| Acceleration voltage | Utilizes low acceleration voltage or reduction of energy in front of the sample using a decelerating electric field |
| Spot shape | Increased due to the effect of aberrations and diffraction |
| Sample tilting | Cannot be used with sample tilting due to the effect on the emission angle of electrons |
| Radiation damage | Higher radiation damage to the sample compared to other techniques |
| Energy window | Can range from 100 eV to 10 eV with reasonable collection efficiency |
| SE detection | Detects SEs and BSEs |
| Photomultiplier | Converts light information into an electronic signal |
Explore related products
What You'll Learn
- InLens detectors are used in electron microscopes to collect backscattered electrons (BSEs)
- The InLens detector is located in line with the electron source, perpendicular to the sample surface
- InLens detectors can be used for high-contrast topography or compositional contrast examinations
- InLens detectors can be used to image metal nanostructures of various sizes and geometries
- InLens detectors are more sensitive than Everhart-Thornley detectors, resulting in higher-resolution images
InLens detectors are used in electron microscopes to collect backscattered electrons (BSEs)
The InLens detector is located in line with the field emission gun, perpendicular to the surface of the sample. The InLens detector is designed to detect BSEs with high emission angles that intersect the axis far from the lower pole piece of the objective lens. These BSEs have a much higher angular aperture, resulting in greater spherical aberration.
The InLens detector is particularly useful for imaging biological samples, as it can improve resolution by reducing the effect of the large interaction volume of BSEs. This is achieved through the use of simple high-pass filtration, which separates the BSEs from the surface layer of the sample, allowing for clearer imaging.
Additionally, the InLens detector can be used in conjunction with other detectors, such as the Everhart-Thornley detector, to enhance the contrast and composition information obtained from the sample. By combining the topographical information from the InLens detector with the density data from the backscattered electron detector, detailed density-dependent colour SEM images can be created.
