In electric power distribution, a service drop is an overhead electrical line running from a utility pole to a customer's building. Three-phase power allows longer service drops to serve multiple residences, which is economical in Europe's higher-density housing. Each phase wire provides around 230 V and carries 50 Hz alternating current, which is 120° out of phase with the other two. Voltage drop refers to the difference between the voltage supplied at the source and the voltage measured at the load. The voltage drop formula changes depending on the number of phases in the circuit. In a three-phase circuit, the voltage drop equation is: Vd = (1.73K x L x I)/Cm.
| Characteristics | Values |
|---|---|
| Definition | An electrical three-phase drop, also known as a service drop, refers to the overhead electrical lines that run from a utility pole to a customer's building or premises. |
| Voltage Drop Equation | The equation to find voltage drop in a three-phase circuit is: Vd = (1.73K x L x I)/Cm |
| Single-Phase Voltage Drop Equation | The equation to find voltage drop in a single-phase circuit is: Vd = (2K x L x I)/Cm |
| Factors Affecting Voltage Drop | - Conductor material, size, and operating temperature |
| - Phase spacing and number of phases | |
| - Circuit distance and load | |
| Minimizing Voltage Drop | - Improving system efficiency by reducing power consumption |
| - Troubleshooting electrical issues that increase current or resistance | |
| Common Voltages | - 120Y/208, 240V, 480V (three-phase) in the US |
| - 600V three-phase in Canada | |
| - 380-415V or 690V three-phase in Europe and other countries |
